Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Specifications
Brand Name :
Weinas
Model Number :
17R
Certification :
CE,ROHS
Place of Origin :
Guangzhou, China
MOQ :
2 Pieces
Price :
High Quanlity & Reasonable Price
Payment Terms :
T/T, , L/C
Supply Ability :
1000pcs/month
Delivery Time :
3-12 Workdays Depends On Quantity
Packaging Details :
Export Carton Or Flight Case
IP Level :
IP20
Lamp :
Yodn 17R 350W or 16R
Control Mode :
Auto-run, Master-slave, Sound-active Mode
Packing :
Carton or Flight Case
Display :
Touch Screen With 180 degee Revered available
DMX Channle :
16/20CHS
Lens :
Quartz Glass Optical Lens
Color Wheel :
14 colors+white
1 Gobo Wheel :
17 static gobos+white
2 Gobo Wheel :
7 replaceable gobos+white with rotational
Prism :
1PCS 24 facet prisms and 1PCS 24 facet prisms
Pan :
540 Degree 16bit
Tilt :
270 Degree 16bit
Strobe :
1-13 times / second
Dimmer :
0-100% dimmer
Frost :
0-100% Frost
Description

Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light


Weinas-17R


Function Specifications

Voltage AC220V-240V 50/60Hz
Lamp

YODN 17r 350w, 16R 330W
Rated Power 500W
Len 0-5°Optical lens group
Display Touch Screen with 180 degree reversed available, with four buttons
Control mode 16/20 Channels optional,Art-net light control protocol and
wireless DMX512 control (optional)
Pan Movement 540 degree (16Bit scanning accuracy)
Tilt Movement
270 degree (16Bit scanning accuracy)
Color wheel 14 dichroic filters + open, with half color effect
Static gobo wheel 17 gobos + open
Rotation gobo wheel 8 replaceable and bidirectional glass gobos + open
Prism 1 pcs 24 facet circular prism with 3 layers + 1 pcs 24 facet circular prism with one layer rotating in both directions at variable speed + 1pcs fixed prism
Strobe Double and pole strobe maximum reaches 13 times per second,
random strobe and pulse strobe optional
Dimmer 0%-100% linear dimmer
Foggy 0~100% linear foggy
IP rate IP20 high efficiency switch power supply
Other Function Other function: Lamp on/off function and reset through controller.
Auto-run, Master/slave, Sound active mode.




DMX Channles Function

Started mode Simple mode STANDARD (22 and 16 you can choose)
CH1 CH1 Pan
CH2 CH2 Tilt
CH3 * Pan fine
CH4 * Tilt fine
CH5 * Pan& Tilt speed
CH6 CH3 focus
CH7 CH4 Strobe
CH8 CH5 Dimmer
CH9 CH6 Color wheel
CH10 CH7 Color effect
CH11 CH8 Static gobo wheel
CH12 CH9 Rotating Gobo wheel
CH13 CH10 Gobo Rotating of Rotational Gobo Wheel
CH14 * Gobo Shaking
CH15 CH11 All the prisms
CH16 CH12 Prism 1 rotation
CH17 CH13 Prism 2 rotation
CH18 CH14 Marcos
CH19 CH15 Frost
CH20 CH16 Lamp off 100-105, on 200-205, Reset 255

Effet And Testing Pictures


Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light

Dmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco LightDmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco LightDmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco LightDmx512 17R 350W Professional Wash Beam Spot Stage Moving Head Lighting Disco Light
