PWM Solar Panel Protection Solar Charger Charge Controller
PWM Solar Panel Protection Solar Charger Charge Controller
PWM Solar Panel Protection Solar Charger Charge Controller
PWM Solar Panel Protection Solar Charger Charge Controller
PWM Solar Panel Protection Solar Charger Charge Controller
PWM Solar Panel Protection Solar Charger Charge Controller
Specifications
Brand Name :
SZSSTH/OEM
Model Number :
SZSSTH-MN1230, PWM
Place of Origin :
Guangdong, China
Price :
CN¥124.27/pieces 1-99 pieces
Supply Ability :
2500 Piece/Pieces per Week
Packaging Details :
Packing: gift box
Quantity/carton: 50pcs in one carton
Type :
PWM
Application :
Charger Controller, Voltage Controller, Solar System Controller, charger controller
Work Time (h) :
24h
Max PV Power :
1050w
Max PV Voltage :
100v
Rated Voltage :
12v 24v
Maximum Current :
30A
Warranty :
1 Years, 1 Year
Weight :
780g
Color :
Green
Product name :
solar charge controller module
Keywords :
solar charge controller 30a
Certificate :
CE ROHS
Port :
Yantian or Shekou
Description

PWM Solar Panel Protection Solar Charger Charge Controller

Ideal Applications

  • Small Off-Grid Systems: Powers cabins, RVs, boats, and gate operators with efficient energy management

  • Backup Lighting: Reliable control for solar street lights, garden lamps, and security systems

  • Agricultural Use: Cost-effective solution for livestock fencing, irrigation controllers, and remote monitoring stations

Technical Specifications

  • Max PV Input: 50V DC

  • Charging Current: 30A

  • Standby Consumption: <10mA

  • Compatible Batteries: Sealed/Flooded/GEL

  • Terminal Size: 8mm²

Secure Your Solar Power – This factory-direct PWM controller offers essential protection without complex setups. Compatible with 100W-700W solar arrays, it’s the economical guardian for entry-level renewable energy systems. Includes 18-month warranty and IP32-rated casing for dependable service.

Model
20A
30A
40A
50A
60A
System voltage
12V/24V, 24V /48V (Automatically switch)




The Maximum voltage of the solar panel input
50V (12/24V) ,100V (24V/48V)




Self loss
<13mA




Maximum charge current
20A
30A
40A
50A
60A
Maximum discharge current
20A
30A
40A
50A
60A
LVD
10.5V (9-11V), 21V (18V-22V), 42V (36V-44V)




LVR
12.6V(11-13.5V), 25.2V( 22-27V), 50.4V( 45-54V)




Battery overpressure protection
15V /30V /60V




Charging mode
PWM




Terminal scale
28-10 AWG




Waterproof level
IP32




Product size
187*90*47mm

195*107*50mm
187*122*57mm

Packing size
200*102*53mm

210*118*59mm
200*132*63mm

Weight
780g


850g


PWM Solar Panel Protection Solar Charger Charge Controller
PWM Solar Panel Protection Solar Charger Charge Controller
