Specifications
Brand Name :
SZSSTH
Model Number :
M56
Place of Origin :
Guangdong, China
MOQ :
100 watts
Price :
CN¥11.86/watts 100-9999 watts
Cell size :
156.75mmx156.75mm
Panel Dimensions :
2583mmx973mm
Panel Efficiency :
15.2/15.6/15.8/16/16.3/16.5%
Product name :
thin film CIGS flexible rollable solar panel
Power :
350W/360W/365W/370W/375W/380W
Max voltage :
29.6V/29.8V/30V/30.1V/30.2V/30.3V
Max Current :
11.83A/12.07A/12.19A/12.31A/12.43A/12.55
Waterproof grade :
IP67
Fire-proof grade :
B1
Hail-proof grade :
Level 4
Minimum thickness :
only 20mm thickness
Description

Minimum Thickness 350W 360W 365W 370W 375W 380W CIGS Flexible Solar Panels for Solar Energy System

350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
M56
M56-350
M56-360
M56-365
M56-370
M56-375
M56-380
Nominal Power
Pmpp
[W]
350
360
365
370
375
380
Aperture Efficiency
[%]
15. 2
15.6
15.8
16
16. 3
16.5
Power Output Tolerance
[W]
0~+5
0~+5
0~+5
0~+5
0~+5
0~+5
Maximum Power Voltage
Vmpp
[V]
29. 6
29.8
30
30.1
30. 2
30.3
Maximum Power Current
Lwpp
[A]
11.83
12. 07
12. 19
12. 31
12.43
12.55
Open Circuit Voltage
Voc
[V]
37. 2
37.3
37.3
37.6
37.6
37. 6
Short Circuit Current
lsc
[A]
13.78
13.88
13. 93
13.98
14. 07
14. 1
Maximum Series Fuse Rating
[A]
25
Standard Test Conditions :1000W/m.25C Cel1 temperature,AM 1.5 spectrum
THERMAL CHARACTERISTICS
NOCT
['c]
48
Temperature Coefficient Of Pmpp
[%/'℃]
-0. 38
Temperature Coeffioient Of Voc
[%/c]
-0. 28
Temperature CoeffioientOf lsc
[%/'c]
0
CelI Temperature Opera Ting Range
['c]
-40~85
PHYSICAL AND MECHANICAL SPECIFICATIONS
Length
2583mm
Width
973m
Thickness maximum AtJ-Box*
20mm
Weight module without adhesive)
2.9kg
Weight module with adhesive)
3.5kg
Weight/Area module without adhesive)
1. 7kg/m²
Weight/Area module with adhesive)
2. 1kg/m²
CelI Type
CIGS
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
More Than 30,000 Customers Are Attracted By Our Company, Because We Strictly Control The Installation And Inspection Of Electrical Products Before Leaving The Factory And The Test Before Delivery, So That We Can Do The Best We Can, So That Our Customers Can Use Our Products At Ease
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
We Have Passed Rohs Certification, Ce Certification, Bsci, Vertified Certification And Design Patent And Other International Certifications. Strictly Control Materials, Processing, Assembly, Debugging, Testing, Packaging, Transportation And Other Links To Ensure The Performance And Quality Of Electrical Products
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
Rated Products
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
Q1: I would like to test the sample, but the shipping cost is too high, how to proceed to the next step?
A1: This is just the sample order, we have already offered the best cost. It would be some kind of high on shipping, while it worth it -- checking the real quality of goods, and making sure it is the right one we need. For our bulk order, we can choose a better delivery method like sea delivery, unit shipping cost would be greatly lower. All we wish is long-time business,win-to-win.

Q2: If our client wants to use a power inverter for the lithium battery, would it be possible?
A2: Our power inverter voltage range is set according to standard Lead-acid batteries, it would be some kind of difference from the lithium battery parameter. Pls show us your exact parameter of yours, then our Engineer will specially customize them for you in our factory.

Q3:Do you accept OEM service?
A3: Yes, We support OEM/ODM service.

Q4: Can I take a sample for a test?
A4: Yes, a Sample is available for us.

Q5: How do I pay you?
A5: We accept Insurance order, It support T/T, Credit card, Paypal, Western Union, etc method.

Q6: What kind of warranty for your product?
A6:We provides one year warranty.

Q7:What is your terms of payment?
A7: T/T 30% as deposit, and 70% balance before shipment.

Q8: What are your terms of delivery?
A8: EXW, FOB, CFR, CIF, DDU.DDP

Q9:Can you print our brand on the product?
A9: Yes, We can. The MOQ:50PCS.
Remark: For the 150w /300w inverter (Red color dc 12v to ac 110v ), We can print your logo on the product for free.

Q10: How much does the shipping cost?
A10: Can you tell me how many pcs do you need? Please also send me your shipping address and zip code. Then I check how much the shipping cost was.
350W 360W 365W 370W 375W 380W CIGS Solar Panels Soft Solar Panels 2583mmx973mm
