100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
Specifications
Place of Origin :
Guangdong, China
Brand Name :
SZSSTH
Model Number :
2400W
Price :
CN¥2,692.04/pieces 1-99 pieces
Network :
SDK, nfc
Type :
DC/AC Inverters
Output Type :
Single
Output Current :
100A
Size :
300*198*80mm
Weight :
6.5 KG
Product name :
12vdc to 24vdc 100a dc to dc converter 2400W
Input voltage :
12Vdc
Output voltage :
24Vdc
Waterproof :
IP68
Protection :
Overload/over-current,etc.
Efficiency :
96%
Application :
LED strp/Motor/truck
Advantage :
Ultra compact size, light weight , high reliability
Color :
Silver
Customized support :
Software reengineering
Certificate :
CE, ROHS
Description

100A Output Current 2400W Full Power Boost Voltage Step Regulator 12VDC to 24VDC DC to DC Converter for Network SDK

Products Description
Factory directly sale high power 2400Watt boost voltage step regulator 12vdc to 24vdc 100a dc to dc converter 2400W
Feature:
> Full power, stable voltage & current output.
> Wide input voltage range.
> Waterproof & anti-shock protection, Ultra compact size, light weight.
> Industry grade product 12v to 24v dc converter 100a, efficiency up to 96%.
> Die-cast aluminum shell, epoxy potting.
> Non-Isolated Module.
> 12 months warranty.
Product Paramenters
Product Name
2400W dc 12v to 24v boost voltage regulator
Input rated voltage
12V DC
Input voltage range
10-15V DC
Conversion Efficiency
96%
Output voltage
24V DC
Output current
100 Amps
Output rated power
2400 Watts
Voltage regulation
< 1%
Load regulation
< 2%
Ripple (full load test)
< 150mV
No-load current
< 20mA
Working Temperature
-40°c ~ +80°c
Waterproof rating
IP 68
Protections
Over-load, Over-current, Over-temperature, Over-voltage
Machine size
300*198*80mm
N. Weight
6.5kg
Cooling way
Free air convection
Details Images
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
100A 2400W 12VDC To 24VDC Converter For Network SDK Single Output
