2000W Pure Sine Wave Inverter 12V/24V/48V to 110V/220V
2000W Pure Sine Wave Inverter 12V/24V/48V to 110V/220V
Specifications
Brand Name :
SSTH
Model Number :
RS-12000
Place of Origin :
Guangdong, China
MOQ :
1
Price :
＄110-332/pieces 1-99 pieces
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Piece/Pieces per Month
Packaging Details :
carton
Input Voltage :
12V/24V/48V
Output Voltage :
110V/220V
Output Current :
70A/35A
Output Frequency :
50Hz/60Hz
Output Type :
Single, Pure sine wave
Size :
390cm*222cm*178cm
Type :
DC/AC Inverters
Inverter Efficiency :
90%
Weight :
15kg
Product name :
Pure Sine Wave 2000W Inverter
Model :
SSTH-RS2000W
Certificate :
CE Rohs
Port :
shekou
Description

Product Overview

This 1000W--6000W low-frequency toroidal transformer solar inverter is designed for off-grid solar systems, RVs, and home backup power. Featuring a pure sine wave output, it ensures stable voltage for sensitive electronics like medical equipment, refrigerators, and power tools. The toroidal transformer enhances efficiency (up to 92%) and reduces energy loss, making it ideal for 24V/48V solar battery systems.

Certified Safety – CE, RoHS, ISO9001 compliant
Wide Compatibility – Works with lead-acid/LiFePO4 batteries
Silent Operation – Low-noise cooling fan for indoor/outdoor use

Model
RS2000
RS3000
RS4000
RS5000
RS6000
Rated Power
2000W
3000W
4000W
5000W
6000W
INPUT
Voltage
100/110/120Vac, 220/230/240Vac
Selectable Voltage Rang
Wide Range: 75vac - 138vac, 155vac - 275vac (For Home Appliances)
Narrow Rang: 82vac -138vac, 165vac - 275vac (For Peronal Computer)
Frequency Range
40-70Hz(50Hz/60Hz)
OUTPUT
AC Voltage Regulation
Vout (±10V)
Surge Power
4000VA
9000VA
12000VA
15000VA
18000VA
Efficiency (Peak)
88%
91%
Transfer Time
＜20ms
＜10ms
Waveform
Pure Sine Wave
BATTERY
Battery Voltage
24V
24V
48V
24V
48V
24V
48V
24V
48V
Charge Current
35A
50A
25A
70A
35A
75A
45A
75A
50A
Fast Charge Voltage
28.6VDC
28.6 VDC
57.2 VDC
28.6 VDC
57.2VDC
28.6 VDC
57.2 VDC
28.6 VDC
57.2 VDC
Float Charge Voltage
27.4VDC
27.4
VDC
54.8
VDC
27.4 VDC
54.8VDC
27.4 VDC
54.8 VDC
27.4 VDC
54.8 VDC
Over Charge Voltage
33.0VDC
33.0 VDC
66.0
VDC
33.0 VDC
66.0 VDC
33.0 VDC
66.0 VDC
33.0 VDC
66.0 VDC
Battery low Voltage
Alarm
21.0VDC
21.0
VDC
42.0
VDC
21.0 VDC
42.0VDC
21.0 VDC
42.0 VDC
21.0 VDC
42.0 VDC
Battery low Voltage Shutdown
20.0VDC
20.0
VDC
40.0
VDC
20.0
VDC
40.0
VDC
20.0
VDC
40.0
VDC
20.0
VDC
40.0
VDC
Protection
Over Charging, Over Temp, Over Battery voltage, Over load, short-circuit
Operating environment temperature

55℃
Cooling
Intelligent Fan
Display
Color LCD
Specification Setting
By LCD or Position Machine:
Charging Current, Battery Type, Input Voltage, Output Frequency, Wide and Narrow rang of AC Input voltage, Power-Saver Model,
AC Priority or Battery Priority
PHYSICAL
Dimension
D*W*Hmm
390*222*178
500*258*190
574*345*197
574*345*197
574*345*197
Net Weight (kgs)
15
25.2
24.6
34.4
33.8
37.9
38.2
41.6
40.5
ENVIRONMENT
Humidity
5~95% Relative Humidity (Non-condensing)
Operating Temperature
-10℃ to 50℃
Storage Temperature
-15℃ to 60℃

Key Features & Benefits

1. High-Efficiency Toroidal Transformer

  • Lower heat generation vs. traditional EI transformers

  • Compact & lightweight design saves installation space

  • Higher surge power (6000W peak) for motor-driven devices

2. Pure Sine Wave Output (3000W Continuous)

  • Safely powers medical devices (CPAP), laptops, and LED lighting

  • No interference with Wi-Fi, audio systems, or sensitive electronics

3. Multi-Protection Systems

  • Overload / Short-circuit / Over-temperature / Low-voltage shutdown

  • Automatic recovery after fault clearance

4. Solar & Battery Compatibility

  • Input Voltage: 24V/48V DC (customizable)

  • AC Output: 110V/120V (US) or 220V/230V (EU) – Selectable model

  • Supports parallel operation for higher capacity

    2000W Pure Sine Wave Inverter 12V/24V/48V to 110V/220V

    2000W Pure Sine Wave Inverter 12V/24V/48V to 110V/220V



    Ideal Applications

    Off-grid solar systems (with solar panels + batteries)
    RV/Camper/Marine power – Quiet and vibration-resistant
    Home backup during outages – Runs refrigerators, lights, and routers
    Workshops & farms – Supports power tools and pumps

    Why Choose Our Inverter?

    5-Year Warranty – Industry-leading reliability
    OEM/ODM Support – Custom logos, voltages, and designs
    24/7 Technical Support – Pre-sale consultation + after-sale service
