Duplex 2205 Stainless Steel Sheet 0.8mm Anti Fingerprint AS/NZS 4673
Duplex 2205 Stainless Steel Sheet 0.8mm Anti Fingerprint AS/NZS 4673
Specifications
Brand Name :
Baosteel,TISCO，WISCO，CHINA STEEL UNION
Model Number :
Thickness 0.1mm-50mm, or customized
Certification :
ISO9001,SGS, ASTM, ASME
Place of Origin :
CHINA
MOQ :
1000Kilogram
Price :
USD256-830
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
800000KG/15Days
Delivery Time :
2-3Days
Packaging Details :
Steel strip + kraft paper + fumigated wooden box export exquisite packaging
Protection :
PVC film, inner paper
Tensile Strength :
800mpa
Surface :
2B, BA, No.4, HL, Mirror
Edge :
Mill Cut Edge
Size :
1000*2000mm|1219*2438mm
Surface Treatment :
BA/2B/ NO.4/ 8K/ HL
Description

​​2205 Duplex Stainless Steel Sheet (0.8mm thick, 1220×2440mm)​​ is a premium architectural material engineered for modern high-performance building exteriors, compliant with AS/NZS 4673 standards. Featuring a dual-phase microstructure, it combines superior strength with an anti-fingerprint coating to ensure aesthetic durability in urban environments.

The 0.8mm thickness delivers lightweight rigidity, while its high chromium/molybdenum/nitrogen content provides exceptional resistance to atmospheric corrosion, chloride exposure, and pollution. The anti-fingerprint finish maintains pristine appearance for facades, cladding, and decorative elements in high-traffic areas.

Duplex 2205 Stainless Steel Sheet 0.8mm Anti Fingerprint AS/NZS 4673

Detailed Specifications

​Parameter​ ​Details​
​Material​ 2205 Duplex Stainless Steel (UNS S32205 / EN 1.4462)
​Element Composition Cr: 22–23%, Ni: 4.5–6.5%, Mo: 3.0–3.5%, N: 0.14–0.20%, Mn: ≤2%, Si: ≤1%, C: ≤0.03%, Fe: Balance
​Dimensions​ 1220mm x 2440mm (4ft x 8ft); Thickness: 0.8mm (±0.03mm tolerance)
​Surface Finish​ Anti-Fingerprint Coated (PVDF or Nano-Ceramic), No. 4 Brushed
​Certifications​ AS/NZS 4673, ASTM A240, ISO 12944 (corrosion resistance), LEED Compliance
​Mechanical Properties Tensile Strength: ≥620 MPa
Yield Strength: ≥450 MPa
Elongation: ≥25%
Hardness: ≤290 HB
​Applications​ Building facades, curtain walls, elevator interiors, outdoor sculptures



​​Advantages of Importing:​​

Architectural Durability: Duplex structure provides 2x higher strength than 304/316 steels, reducing material usage; Aesthetic Maintenance: Anti-fingerprint coating resists smudges/graffiti, cutting cleaning costs by 40%;

AS/NZS Compliance: Certified for Australian/New Zealand structural standards, ideal for coastal/urban projects; Custom Solutions: Pre-fabricated panels, perforated designs, curved profiles for bespoke architecture; Fast Logistics: 12-18 day delivery from Shanghai/Sydney ports with anti-scratch packaging. ​​

Key Applications:​​

High-Rise Facades: Corrosion-resistant cladding for coastal/industrial skyscrapers; Transit Hubs: Durable panels for airports/metro stations/bus terminals; Luxury Interiors: Elevator linings/decorative columns/art installations; Sustainable Buildings: LEED-compliant projects using recyclable materials/low-maintenance surfaces.
