Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated
Specifications
Brand Name :
guanbiao
Model Number :
Customizable
Certification :
ISO9001
Place of Origin :
China
MOQ :
50000
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
5000000
Delivery Time :
15-20 work days
Packaging Details :
Plastic bag + carton + pallet
Corrosion Resistance :
Good
Country Of Origin :
China
Usage :
Adjusting eccentricity
Exterior :
smooth
Tooth :
no
Color :
Natural color of stainless steel
Shank Diameter :
5mm
Material :
Stainless Steel
Drive Type :
Torx
Size :
M8-M10, Customizable
Use :
Fixing adjustment
Load Capacity :
100kg
Description

Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated

High-strength Torx eccentric screws for precision mechanical adjustment. Grade 10.9 alloy steel, ±1-2mm offset. Dacromet coated. Resists vibration & corrosion. M8-M20 sizes. Custom offsets/coatings.

Engineered for critical alignment applications, **Torx Eccentric Screws** feature an **off-center shaft** (eccentric design) enabling micro-adjustment of mechanical components. The **Torx drive (TX/TXH)** ensures maximum torque transfer without cam-out, while Grade 10.9 alloy steel withstands heavy loads and vibration. Ideal for compensating tolerances in industrial machinery.

Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated


TECHNICAL SPECIFICATIONS
Drive Type Torx (TX/TXH) - e.g., TX40 for M10
Eccentric Offset (e) ±1mm, ±1.5mm, ±2mm
Sizes M8, M10, M12, M16, M20
Length 20-100mm (Customizable)
Material Alloy Steel 40Cr (Grade 10.9)
Surface Treatment Dacromet Coating (800hrs salt spray resistance)
Offset Direction Fixed or 360° adjustable (Custom)

Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated


Primary Uses & Applications:

- Conveyor belt tracking adjustment
- Gearbox/pump shaft alignment
- Industrial robot joint calibration
- Press tooling positioning
- Railway bogie shimming


Industrial Torx Eccentric Screws Grade 10.9 Alloy Steel ±2mm Offset Machinery Alignment Dacromet Coated


How to Use:

1. Insert screw through misaligned components.
2. Rotate with **Torx bit** to leverage eccentric offset (e).
*Example: 180° rotation = 2× offset value (e.g., ±2mm → 4mm total adjustment)*
3. Tighten to 80% of rated torque for Grade 10.9.
4. Secure with locknut (sold separately).
