Cold Drawn Pre Painted Aluminium Coil
Cold Drawn Pre Painted Aluminium Coil
Cold Drawn Pre Painted Aluminium Coil
Cold Drawn Pre Painted Aluminium Coil
Cold Drawn Pre Painted Aluminium Coil
Cold Drawn Pre Painted Aluminium Coil
Specifications
Model Number :
2024
Certification :
Material Test Certificate
MOQ :
120m
Price :
Translation Price
Payment Terms :
L/C At Sight,, T/T, Western Union
Supply Ability :
3000Tons/Month
Delivery Time :
10-15 work days
Packaging Details :
Kraft Paper+Wooden Pallet+Wooden Box
Product Name :
2024 Color Coated Aluminum Cold Hot Drawn Coil Roll
Material :
2024
Application :
Building
Temper :
O - H112
State :
Hot Cold Drawn
Coat :
Color
Description

2024 Color Coated Aluminum Cold Hot Drawn Coil Roll Building Material

Product Description

2024 aluminum is a typical hard aluminum alloy in the Al-Cu-Mg series. It is used most in 2 series alloys. And It’s not difficult to find that the strength of 2024 aluminum alloy is very high. When the temperature is higher than 125℃, its strength is higher than that of 7075 alloy. In addition, the heat treatment strengthening effect of the 2024 aluminum plate is the most significant. Whether it is in the hot state, annealed or newly hardened, its formability and machinability are very good. However, the heat treatment process of 2024 aluminum alloy is strict. It is mainly used for making various high load parts and components (but not stamping forgings) such as aircraft skeleton parts, skins, spacer frames, wing ribs, wing beams, rivets, and other working parts below 150 degrees.

Product Display

Grade
2024
Trade Terms
FOB/CNF/CIF
Supply Ability
2000-3000 Ton/month
Packing
standard exporting packing or at buyer’s requirement
Width
100-2200mm
Thickness
0.6-1.35mm
Coating paint
PVDF/PE
Delivery time
Within 15-30days after we receive deposit or L/C at sight
Type
coil

Content
Performance of PE Coating
Performance of PVDF Coating
Color Difference
∆E ≤ 2.0
∆E ≤ 1.5
Gloss Difference
≤5
≤5
T-bend
≤3T
≤3T
Adhesion Grade
0
0
Impact
≥20kg.cm
≥50kg.cm
Solvent Resistance
200 times no break
200 times no break
Acidity Resistance
5％ HCL 24hrs no change
5％ HCL 24hrs no change
Alkali Resistance
5％ NaOH 24hrs no change color
5％ NaOH 24hrs no change color
Salt Spray Resistance
720hrs ≤Grade le
720hrs ≤Grade le
Abrasion Resistance
≥5L/μm
≥5L/μm

Cold Drawn Pre Painted Aluminium CoilCold Drawn Pre Painted Aluminium CoilCold Drawn Pre Painted Aluminium Coil

Polyester Painted Aluminum Coil(PE)

The polyester painted aluminum coil is made by coating polyester paint which can form
varied decorative film on the aluminum surface.Produced by advanced roller coating process, PE aluminum sheet has excellent
painting and high performance. All the parameters of our products are able to meet or much higher than related national standards.
Cold Drawn Pre Painted Aluminium Coil

PVDF Coated Aluminum Coil

The PVDF coated aluminum coil uses PVDF paint of famous brands like PPG, VALSPAR and
NIPPON, which goes through duplex or triplex coating and high temperature baking to form 25-35μm thick cured coating. As the PVDF
coating provides corrosion resistance, high weatherability, strong adhesion, high self-cleaning capability and is
maintenance-free, the aluminum coated coil can remain color fast and durable for 10-15 years.
Cold Drawn Pre Painted Aluminium Coil

Application

1. Exteror applications such as: wall cladding, facades, roofs and canopies, ACP, tunnels, column covers or renovations, etc.

2. Interior applications such as: wall cladding, ceilings, bathrooms, kitchens and balconies, etc.

3. Advertisement and market applications such as: display platforms, signboards, fascia and shop fronts, etc.

4. Transportation and industry, etc.
