AMS 5734J Stainless Steel Flat Bar UNS S66286 Forgings
AMS 5734J Stainless Steel Flat Bar UNS S66286 Forgings
AMS 5734J Stainless Steel Flat Bar UNS S66286 Forgings
AMS 5734J Stainless Steel Flat Bar UNS S66286 Forgings
AMS 5734J Stainless Steel Flat Bar UNS S66286 Forgings
AMS 5734J Stainless Steel Flat Bar UNS S66286 Forgings
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AMS 5734J, UNS S66286, ASTM Grade 660
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
1500kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
45000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
High strength, Corrosion Resistance
Heat treatment condition :
+AT, +P, etc.
Processing methods :
Ground,Peeled. etc
Available Shapes :
Bars, Wire, Tubing, Forgings...
Surface :
Grinding, Centreless Ground, etc.
Application :
Turbine rotors, Vanes, Shafts, Blades, Dowels, Flanges, Fittings
Material Category :
Austenitic stainless steel
Description

AMS 5734J Stainless Steel Flat Bar UNS S66286 Forgings
Describe

A precipitation hardening stainless steel, NAS 660 (SUH 660, UNS S66286), retains excellent strength at high temperatures up to 700°C, surpassing austenitic stainless steels. NAS 660 has a higher nickel content than Type 304 and also includes elements such as titanium and aluminum for hardening. Age hardening is used to precipitate the γ' phase [Ni3 (Al, Ti)], making it a very strong metal at high temperatures.

Size Range

Round bar / Wire rod (Diameter): 3.0mm to 900mm
Square bar / Flat bar: 3.0mm to 900mm
Forging piece:

Stepped shafts with flanks / discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 250mm X W10 - 1550mm X L1000-11000mm

Sheet steel via cold rolled:

T0.5 - 4mm X W6 - 1000mm X L1000 - 1000mm

Steel strip via cold rolled:

T0.1 - 3.0mm X W5 - 180mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5734J
standard SAE AMS 5734J-2001
Chemical Composition (weight%)

C(％): ≤0.8 Ti(％): 1.90~2.35
Si(％): ≤1.0 B(％): 0.003~0.01
Mn(％): ≤2.0 V(％): 0.10~0.50
P(％)≤: 0.025 Co(％): ≤1.00
S(％)≤: 0.025 Al(％): ≤0.35
Cr(％): 13.5~16.0 Cu(％): ≤0.50
Ni(％): 24.0~27.0
Mo(％): 1.0~1.50


AMS 5734J Stainless Steel Flat Bar UNS S66286 Forgings


Mechanical Properties


AMS 5734J Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa: 965
Yield strength,Rp/MPa: 655
Elongation/%: 12
Reduction of area, ψ/%: 15
Impact, KV /J: --
Annealed hardness HBS: --
