AMS 5661 Turbine Blade Steel UNS N09901 Solid Square Bar
AMS 5661 Turbine Blade Steel UNS N09901 Solid Square Bar
AMS 5661 Turbine Blade Steel UNS N09901 Solid Square Bar
AMS 5661 Turbine Blade Steel UNS N09901 Solid Square Bar
AMS 5661 Turbine Blade Steel UNS N09901 Solid Square Bar
AMS 5661 Turbine Blade Steel UNS N09901 Solid Square Bar
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AMS 5661E, UNS N09901, AMS 5661
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
1200kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
40000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Corrosion and Heat-Resistant
Heat treatment condition :
+AT, +P, etc.
Processing methods :
Ground,Hot Working, Machined, etc
Available Shapes :
Steel strip via cold rolled, Forging piece, Tubing, etc
Surface :
Rrough Turned, peeled + polishing, etc.
Application :
Pressure Vessels, Valves, Flanges...
Material Category :
Fe Ni Cr Precipitation Hardening Alloy
Description

AMS 5661 Turbine Blade Steel UNS N09901 Solid Square Bar

Production Information

Alloy 901 is an age-hardenable super alloy which contains Titanium and Aluminium for precipitation hardening and molybdenum for soild-solution strengthening. Alloy 901 has high yield strength and creep at temperatures around 1110°F (600°C). Alloy 901 is able to combine strength with good forging characteristics due to its high iron content. Alloy 901 is commonly used in gas turbine engine discs, shafts, rings, bushings and seals.

Size Range

Round bar / Wire rod (Diameter): 3.0mm to 900mm
Square bar / Flat bar: 5.0mm to 1100mm
Forging piece:

Stepped shafts with flanks / discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 100mm X W10 - 1300mm X L1000-10000mm

Sheet steel via cold rolled:

T0.5 - 5.5mm X W6 - 1000mm X L1000 - 11000mm

Steel strip via cold rolled:

T0.1 - 5.0mm X W5 - 150mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5661E
standard SAE AMS 5661E-1995
Chemical Composition (weight%)
C (％): ≤ 0.10 B (%): 0.010 ~ 0.020
Mn (％): ≤ 1.00 Cu (%): ≤ 0.50
Si (％): ≤ 0.60 Co (%): ≤ 1.00
P (％)≤: 0.030 Pd (%): ≤ 5 ppm
S (％)≤: 0.030 Bi (%): ≤ 0.3 ppm
Cr (％): 11.0 ~ 14.0 Fe (%): balance
Ni (％): 40.0 ~ 45.0
Mo (%): 5.00 ~ 7.00
Ti (%): 2.35 ~ 3.10
Al (%): ≤ 0.35


AMS 5661 Turbine Blade Steel UNS N09901 Solid Square Bar


Mechanical Properties


AMS 5661 Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa: ≥1138
Yield strength,Rp/MPa: ≥827
Elongation/%:

≥12
Reduction of area, ψ/%:

≥15
Impact, KV /J: --
Annealed hardness HBS: 302~388
