AMS 5611 Stainless Steel Flat Bar UNS S41001 Forging Piece
AMS 5611 Stainless Steel Flat Bar UNS S41001 Forging Piece
AMS 5611 Stainless Steel Flat Bar UNS S41001 Forging Piece
AMS 5611 Stainless Steel Flat Bar UNS S41001 Forging Piece
AMS 5611 Stainless Steel Flat Bar UNS S41001 Forging Piece
AMS 5611 Stainless Steel Flat Bar UNS S41001 Forging Piece
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AMS 5611, UNS S41001, AMS 5611G
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
500kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
10000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Corrosion and Heat-Resistant
Heat treatment condition :
+A +P, etc.
Processing methods :
Ground, Milled, Cold working, etc
Available Shapes :
Bars, Wire, Forgings, Plates
Surface :
Grinding, etc.
Application :
These products are typically used in parts requiring uniform high room temperature tensile properties at oxidation resistance up to 1000 °F (538 °C)
Material Category :
--
Description

AMS 5611 Stainless Steel Flat Bar UNS S41001 Forging Piece

Size Range

Round bar / Wire rod (Diameter): 3.0mm to 500mm
Square bar / Flat bar: 3.0mm to 500mm
Forging piece:

Stepped shafts with flanks/discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5 - 500mm X W10 - 1500mm X L1000-11000mm

Sheet steel via cold rolled:

T0.3 - 5mm X W10 - 1000mm X L1000 - 1000mm

Steel strip via cold rolled:

T0.5 - 5.0mm X W5 - 180mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5611

 UNS S41001
standard SAE AMS 5611G-2021 - -
Chemical Composition (weight%)


C(％): 0.12~0.15
Si(％): ≤0.50
Mn(％): ≤0.60
P(％)≤: 0.025
S(％)≤: 0.025
Cr(％): 11.5~12.5
Ni(％): ≤0.75
Mo(％): ≤0.20
Al(％): ≤0.05

Cu(%): ≤0.50

Sn(%): ≤0.05

N(%): ≤0.18

C(％): ≤0.15
Si(％): ≤1.0
Mn(％): ≤1.0
P(％)≤: 0.025
S(％)≤: 0.025
Cr(％): 11.5~13.5
Ni(％): ≤0.75
Mo(％): ≤0.50
Al(％): ≤0.05

Cu(%): ≤0.05

Sn(%): ≤0.05


AMS 5611 Stainless Steel Flat Bar UNS S41001 Forging Piece


Mechanical Properties


AMS 5611 Stainless Steel Round Bar Mechanical Properties

Tensile strength, Rm/MPa: ≥1241
Yield strength, Rp/MPa: ≥1000
Elongation/%: ≥10
Reduction of area, ψ/%: ≥30
Impact, KV /J: --
Annealed hardness HRC: 39~44
