AMS 5663 Turbine Blade Steel UNS N07718 Plates
AMS 5663 Turbine Blade Steel UNS N07718 Plates
AMS 5663 Turbine Blade Steel UNS N07718 Plates
AMS 5663 Turbine Blade Steel UNS N07718 Plates
AMS 5663 Turbine Blade Steel UNS N07718 Plates
AMS 5663 Turbine Blade Steel UNS N07718 Plates
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AMS 5663, UNS N07718, AMS 5663N
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
600kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
50000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Corrosion and Heat-Resistant
Heat treatment condition :
+QT, +AT, etc.
Processing methods :
Peeled, Ground, etc
Available Shapes :
Bars, Forgings, Rings
Surface :
Grinding, Centreless Ground, etc.
Application :
Stainless Steel Flanges, Forged Fittings, Valves, Components
Material Category :
Nickel Alloy
Description

AMS 5663 Turbine Blade Steel UNS N07718 Plates


Size Range

Round bar / Wire rod (Diameter): 5.0mm to 800mm
Square bar / Flat bar: 3.0mm to 500mm
Forging piece:

Stepped shafts with flanks/discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5 - 500mm X W10 - 1500mm X L1000-11000mm

Sheet steel via cold rolled:

T0.3 - 5mm X W5 - 1000mm X L1000 - 1000mm

Steel strip via cold rolled:

T0.3 - 5.0mm X W5 - 180mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5663

 UNS N07718
standard SAE AMS 5663N-2016 ASTM B 637-2018
Chemical Composition (weight%)

C(％): ≤ 0.08 B(％): ≤ 0.006
Si(％): ≤ 0.35 Cu(％): ≤ 0.30
Mn(％): ≤ 0.35 Pb(％): ≤0.0005
P(％)≤: 0.015 Bi(％): ≤ 0.00003
S(％)≤: 0.015 Se(％): ≤0.0003
Cr(％): 17.0~21.0 Co(%): ≤ 1.0
Ni(％): 50.0~55.0
Mo(％): 2.80~3.30
Ti(％): 0.65~1.15
Al(%): 0.20~0.80

Nb+Ta(％): 4.75~5.50

Fe(％):remainder

C(％): ≤ 0.08 B(％): ≤ 0.006
Si(％): ≤ 0.35 Cu(％): ≤ 0.30
Mn(％): ≤ 0.35 Co(%): ≤ 1.0
P(％)≤: 0.015 Nb(%): 0.25~2.5
S(％)≤: 0.015
Cr(％): 17.0~21.0
Ni(％): 50.0~55.0
Mo(％): 2.80~3.30
Ti(％): 0.65~1.15
Al(%): 0.20~0.80

Nb+Ta(％): 4.75~5.50

Fe(％):remainder


AMS 5663 Turbine Blade Steel UNS N07718 Plates


Mechanical Properties


AMS 5627 Turbine Steel Mechanical Properties

Tensile strength, Rm/MPa: ≥1275
Yield strength, Rp/MPa: ≥1034
Elongation/%: ≥12
Reduction of area, ψ/%: ≥15
Impact, KV /J: --
Annealed hardness HB:

≥331

Contact us

Thank you for browsing, if you are interested in our products, please contact us at sales@ss-bars.com, and we will provide you with the best quality quotation

AMS 5663 Turbine Blade Steel UNS N07718 PlatesAMS 5663 Turbine Blade Steel UNS N07718 Plates





AMS 5663 Turbine Blade Steel UNS N07718 Plates
