Ø400mm Digital Vertical Profile Projector VP400-2515

Features:
● The lifting system adopts cross roller rail and precision screw drive, which makes lifting drive more comfortable and stable;
● Coating process reflector, clearer image and great dustproof;
● Adjustable contour and surface illumination, to meet with difference workpiece demand;
● Imported high light and long using life LED illumination ,to ensure precision measurement demand;
● High resolution optical system with clear image and magnification error is less than 0.08%;
● Powerful Bi-axial fan cooling system,highly increase using life;
● Powerful and colorful DRO DP400,realized fast and accurate 2D Measurement;
● Built-in Mini-printer, can print and save data;
● With standard 10X objective, optional 5X, 20X,50X objective,rotary table, foot switch ,clamp, etc.


Specification:

Objective Lens:

Standard Delivery:

Color Screen Multifunction Digital Readout DP400




Features:

● 5.6〃Color Screen and Sealed silicone touch button,with full information, friendly operation, long using life;

● Save 100 permanent image elements, can set and save current date;

● Multi-function Measurement: Point, line, circle,angle, distance, rectangular, screw thread, ellipse, slot, rounding, preset,construction, and so on;

● Obverse or Opposite direction counting function,1/2 value, midpoint, permission function, Call function, REC(record)function,and Cycle measurement;

● Section and linear compensation are available for 3-axis, highly ensure measurement accuracy;

● Can connect foot switch,printer, optical edge detection and other multiple auxiliary measurement tools;

● With polar and coordinate system, and can display millimeter and inch, and can shift easily;

● With independent password permission function, to prevent the posibility of data deviation by wrong operation, it can also change the original setting by password permission;

● Support multiple language:Chinese, English and other language.

Specification:
