High Temperature DIN 2093 Disc Spring Belleville Disk Spring Washers Inconel 718
High Temperature DIN 2093 Disc Spring Belleville Disk Spring Washers Inconel 718
High Temperature DIN 2093 Disc Spring Belleville Disk Spring Washers Inconel 718
High Temperature DIN 2093 Disc Spring Belleville Disk Spring Washers Inconel 718
High Temperature DIN 2093 Disc Spring Belleville Disk Spring Washers Inconel 718
High Temperature DIN 2093 Disc Spring Belleville Disk Spring Washers Inconel 718
Specifications
Place of Origin :
Sihong, China
Brand Name :
Sunzo
Certification :
CE/IATF16949/45001/14001/9001
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
Carton
Delivery Time :
Negotiable
Payment Terms :
Negotiable
Material :
Inconel718, Inconel X-750
Max temperature :
650°C (Inconel718), 750°C (Inconel X-750)
Oxidation resistance :
<0.01mm/year at 600°C
Tensile strength retention :
85% at 500°C
Dish height-to-thickness ratio :
0.6-1.0
Tolerance :
±0.02mm
Modulus of elasticity :
206 GPa (Inconel718)
Fatigue life :
10⁶ cycles at 70% yield strength
Ultimate tensile strength :
1,240 MPa (Inconel718)
Creep resistance :
0.1% strain after 1,000 hours at 650°C/620 MPa (Inconel X-750)
Radiation resistance :
Up to 10⁸ rads
Heat treatment :
Solution annealing at 980°C
Manufacturing tolerance :
±0.05mm
Coating temperature resistance :
Up to 800°C
Thermal cycling range :
-200°C to 700°C
Yield strength :
70% of 1,240 MPa
Precision stamping :
CNC
Surface cleaning :
Ultrasonic
Non-destructive testing :
Eddy current, dye penetrant
Material traceability :
EN 10204 3.1
Description
SUNZO High-Temperature Disc Springs: Inconel718 & Inconel X-750 Engineered Solutions for Extreme Thermal Environments
In extreme temperature environments where conventional spring materials fail, SUNZO high-temperature disc springs—precision-engineered from Inconel718 and Inconel X-750 superalloys—deliver exceptional mechanical stability and thermal resilience.
Material Performance Specifications
These nickel-chromium-based superalloys are specifically formulated to maintain structural integrity across extreme temperature ranges:
  • Inconel718: Operates reliably up to 650°C (1202°F) with minimal creep deformation
  • Inconel X-750: Extends performance to 750°C (1382°F) under cyclic loading conditions
  • Oxidation Resistance: ASTM G111 testing shows <0.01mm/year material loss at 600°C
  • Thermal Strength: Maintains 85% of room-temperature tensile strength at 500°C
Engineering Design & Performance
The unique conical design of SUNZO's high-temperature disc springs—featuring optimized dish height-to-thickness ratios (0.6-1.0) and precision-toleranced geometries (±0.02mm)—enables stable force-deflection characteristics even under thermal cycling.
Inconel718: Modulus of elasticity of 206 GPa with fatigue life exceeding 10⁶ cycles at 70% of yield strength (1,240 MPa ultimate tensile strength)
Inconel X-750: Enhanced creep resistance (0.1% creep strain after 1,000 hours at 650°C/620 MPa) due to γ' precipitate strengthening
Key Applications
  • Aerospace Propulsion: Turbine engine thrust reversers and exhaust nozzle actuators utilizing Inconel718 springs for sustained operation at 600°C
  • Nuclear Energy: Control rod drive mechanisms employing Inconel X-750 springs to maintain critical preload in reactor cores (radiation resistance up to 10⁸ rads)
  • Industrial Furnaces: High-temperature conveyor systems using Inconel718 disc springs in thermal expansion compensation assemblies
  • Gas Turbines: Combustion chamber liners with Inconel X-750 springs providing constant sealing force during thermal transients
Manufacturing & Quality Assurance
Each spring undergoes specialized heat treatment (solution annealing at 980°C followed by aging cycles) to optimize grain structure and precipitate formation. Manufacturing processes include CNC precision stamping (tolerance ±0.05mm) and ultrasonic cleaning to remove surface contaminants.
Custom Engineering Options
  • Coating Systems: Aluminum diffusion coatings for enhanced oxidation resistance up to 800°C
  • Specialized Testing: Thermal cycling validation (-200°C to 700°C) and helium leak testing for nuclear applications
  • Non-destructive Evaluation: Eddy current inspection and dye penetrant testing per ASME BPVC Section V
Backed by ISO 9001:2015 certification and full material traceability (EN 10204 3.1), SUNZO high-temperature disc springs provide engineers with reliable elastic solutions for the most demanding thermal environments. Our technical team offers application-specific design support, including FEA thermal stress analysis and material selection guidance.
