Automotive Paint Mixing Room | Safe, Ventilated Color Prep
Automotive Paint Mixing Room | Safe, Ventilated Color Prep
Specifications
Brand Name :
CoatTech
Model Number :
PT-23
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD5000-USD10000/SET
Payment Terms :
T/T
Supply Ability :
30SET/MONTH
Delivery Time :
15 DAYS After Deposit
Packaging Details :
With regular Film and Carton
NAME :
Automotive-paint-mixing-room
Using Energy: :
Diesel,gas,steam,electric Or Other Option
Main Door: :
Fold Style Or Electric Rolling Style
Motor: :
Chinese Brand Or Import Brand
Control Sytem: :
Switch Style Or PLC Touch Screen Control
Wall: :
Metal Sheld,EPS,Rock Wool Of PU For Option
Color: :
White Or Other Option
Application: :
Bus/truck Or Other Metallic Products
Energy Sources: :
Water, Electricity,gas
Coating :
10-50um
Dimention: :
As Require
Description

Automotive Paint Mixing Room | Safe, Ventilated Color Prep

Eliminate contamination and enhance workplace safety with our state-of-the-art Automotive Paint Mixing Rooms. Designed specifically for the precise preparation of solvent-borne and waterborne automotive coatings, our mixing rooms provide a sealed, heavily ventilated, and brightly illuminated environment. By isolating the paint mixing process from the main shop floor, you protect your inventory from dust, protect your technicians from harmful fumes, and ensure that every color match is flawless before it ever reaches the spray booth.

Key Advantages

  • Superior Fume Extraction: Equipped with a high-efficiency continuous exhaust system that rapidly removes volatile organic compounds (VOCs) and harmful solvent fumes, ensuring a safe, OSHA-compliant environment.

  • True-Color Illumination: Features explosion-proof, daylight-balanced LED lighting arrays that eliminate shadows and color distortion, enabling technicians to achieve pinpoint color accuracy.

  • Contamination Control: Built with interlocking insulated wall panels and a filtered air intake to create a pressurized clean room environment, preventing shop dust from ruining expensive paint batches.

  • Spacious & Organized: Ergonomically designed to comfortably accommodate full-scale paint mixing banks, computerized scales, and stainless steel prep tables without feeling cramped.

  • Built-In Spill Containment: Available with grated flooring over a dedicated spill-containment plenum, keeping the workspace clean and mitigating fire hazards.

Technical Specification Sheet

Parameter Specification
External Dimensions (L x W x H) 3,000 mm x 2,500 mm x 2,800 mm
Internal Dimensions (L x W x H) 2,900 mm x 2,400 mm x 2,750 mm
Airflow Capacity 3,000 m³/h
Exhaust Fan Motor 1 x 1.5 kW Explosion-Proof Centrifugal Fan
Filtration System Primary intake filter (EU3/G3) and exhaust fiberglass filter
Lighting System 4 x 36W Explosion-Proof LED Tubes (Daylight Balanced)
Cabin Construction 50mm EPS / Rockwool insulated panels with anti-static coating
Door Dimensions 1 x Personnel Door (800 mm x 2,000 mm) with observation window
Power Supply 220V / 50Hz / Single Phase (Customizable based on region)
Safety Features Emergency stop button, spark-proof fan, anti-static grounding
Flooring Base Optional 100mm raised steel base with galvanized grating
