YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks
Specifications
Place of Origin :
Guangdong, China
Brand Name :
3nh
Sample Type :
Solid and Liquid
Light Source :
Combined LED Light
Non-Contact Distance :
7.5mm
Measuring Aperture :
20mm
Optical Geometry :
45/0
Warranty :
1 Year
Customized support :
OEM, ODM
Type :
Testing machine
Power :
/
Accuracy :
0.01
Voltage :
100-240v
Protection Class :
/
Description
Product Description

YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks

YL4520 spectrophotometer is a color measuring instrument with 45/0 optical geometry(45 ring-shaped illumination, vertical viewing), to achieve precise non-contact measurement between the measuring probe and the sample like liquids, sauces, powders, etc, which is developed by 3nh independently with independent intellectual property.

YL4520 non-contact benchtop spectrophotometer can be applied for accurate color analysis and transmission in laboratories and R & D industries; it can also be used for accurate color measurement and quality control of automated production lines; it is widely used in cosmetics, fruits and vegetables, food hygiene, plastic electronics, paint and ink, printing, ceramics and other industries. Its unique innovative design can not only provide non-contact measurement scheme directly from the production line, but also ensure stable and high-precision measurement results.

YL4520 non-contact spectrophotometer will not touch the sample in the measurement process, to prevent damage to the sample, but also to avoid cross contamination.

Technical parameters


Model YL4520
Optical Geometry 45/0 method(45 ring-shaped illumination, vertical viewing);Conforms to CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7,GB 2893,GB/T 18833
Features 45/0 non- contact benchtop spectrophotometer can achieve precise non- contact measurement between the measuring probe and the sample like liquids, sauces, powders, etc. It can be applied for accurate color analysis and transmission In laboratories and R & D industries; It can also be used for accurate color measurement and quality control of automated production lines; It is widely used in cosmetics, fruits and vegetables, food hygiene, plastic electronics, paint and ink, printing, ceramics and other industries.
Light Source Full spectrum LED light
Spectrophotometric Mode Concave Grating
Sensor 256 Image Element Double Array CMOS Image Sensor
Wavelength Range 400~700nm/10nm output
Reflectance Range 0~200%
Measuring Aperture Φ20mm
Non-contact Distance 7.5mm
Sample Height 0~150mm
Distance Adjustment Method Manual adjustment(test height can be stored)
Measuring mode Sample mode/QC Mode/Continuous statistics mode
Locating Method Camera Locating
Color Space CIE LAB,XYZ,Yxy,LCh,CIE LUV,HunterLAB
Color Difference Formula ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE(Hunter)
Other Colorimetric Index WI(ASTM E313,CIE/ISO,AATCC,Hunter),YI(ASTM D1925,ASTM E313),

Metamerism Index MI, Staining Fastness, Color Fastness, Color Strength, Opacity
Observer Angle 2°/10°
Illuminant D65,A,C,D50,D55,D75, F1,F2(CWF),F3,F4,F5, F6,F7(DLF),F8 ,F9,F10(TPL5),F11(TL84),F12(TL83/U30)
Displayed Data Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, Chromaticity Graph, Color Simulation, PASS/FAIL Result, Color Offset
Measuring Time About 1.5s
Data Storage Sample mode + QC mode: 30,000; Continuous statistics mode: 10,000

Repeatability
Spectral reflectance: Standard deviation within 0.08%
Chromaticity value: Within ΔE*ab 0.05 (When a white calibration plate is measured 30 times at 5 second intervals after white calibration)
Inter-instrument Error Within ΔE*ab 0.25(Average for 12 BCRA Series II color tiles)
Measurement Mode Single Measurement, Average Measurement(2 ~ 99 times)
Dimension 330*250*370mm
Weight About 10 kg
Power Supply DC 24V, 3A Power Adapter
Illuminant Life Span 5 years, more than 3 million times measurements
Display Screen 7" TFT Capacitive Screen-touch Display
Data Port USB/RS-232
Language Simplified Chinese,Traditional Chinese,English
Working Environment Temperature: 0~40ºC; Humidity: 0~85% (No Condensation); Altitude < 2000m
Storage Environment Temperature: -20~50ºC; Humidity: 0~85% (No Condensation)
Standard Accessory Power Adapter, User Manual, USB cable, Standard Calibration Board, Black Calibration Cavity,
Notes The specifications are subject to change without notice.
Detailed Images

YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks

Industry application

YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks

Advantages

YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks

Company Information

YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks

YL4520 Non-Contact Spectrophotometer Automated Measurement for Cosmetics Food Plastics Inks

FAQ

1. Which brand can 3nh spectrophotometer compare with in the world?
Answer: 3nh instruments can be used to compare with famous brands like Xrite, Minolta, BYK, Datacolor and Hunterlab.

2. Are you a trader or a manufacturer?
Answer: We 3nh is a professional manufacturer from China for 26 years. We research and develop, design and produce, market and sell color measuring instruments and gloss meters, color light box etc.

3. What's your main market?
Answer: We sell to the global market.

4. How long is your delivery time?
Answer: Generally it is 1-3 working days after the payment confirmed.

5. What is your payment terms?
Answer: The payment term is 100% T/T in advance.

6. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.

7. Do you support OEM and ODM service?
Answer: Yes, we support. Our MOQ for OEM and ODM service is 5 pcs for one model.

8. What about the warranty?
Answer: We offer 12 months warranaty for the instrument except consumables, and we offer the lifespan maintenenace for all goods.
