Specifications
Brand Name :
JINSP
Model Number :
SR100Z
Certification :
ISO9001 CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100PCS/30-40 days
Delivery Time :
30-400 working days
Packaging Details :
International Shipping Package
Spectrual Range :
200nm - 1100nm
Effective pixels :
2048*64
Pixel Size :
28.672*0.896mm
Fiber Interface :
SMA905, free space
Numerical Aperture :
0.13
Focal Length :
100mm
Dimensions :
180mm*120mm*50mm
Weight :
1.2kg
Description

Cooled Detector 200nm ~ 1100nm Wide Range Modular Spectrometer

Engineered for spectral excellence, the SR100Z features breakthrough CCD technology with dual cooling-performance advantages. The integrated TE cooling system not only extends sensor lifespan but also enables consistent 70% UV quantum efficiency - critical for precise fluorescence measurements and UV-Vis spectroscopy.

Beyond raw sensitivity, its 2048-pixel spatial resolution and proprietary noise reduction algorithms ensure lab-grade results across applications. Whether analyzing thin-film reflections or capturing weak Raman signals, this spectrometer delivers unmatched SNR through intelligent hardware-software integration.

Product Parameters:

Detector

Chip Type

Back-illuminated TE-cooling Hamamatsu S11850

Effective Pixel

2048*64

Pixel Size

14*14μm

Sensing Area

28.672*0.896mm

Optical
Parameters

Optical Design

F/4 cross type

Numerical Aperture

0.13

Focal Length

100mm

Entrance Slit Width

10μm, 25μm, 50μm, 100μm, 200μm (customizable)

Fiber Interface

SMA905, free space

Electrical
Parameters

Integration Time

4ms~900s

Data Output Interface

USB3.0, RS232, RS485, 20pin connector

ADC Bit Depth

16-bit

Power Supply

5V

Operating Current

＜3.5A

Physical
Parameters

Operating Temperature

10°C ~ 40°C

Storage Temperature

-20°C ~ 60°C

Operating Humidity

＜90%RH (no condensation)

Dimensions

180mm*120mm*50mm

Weight

1.2kg

List of Product Models:

Model

Spectral Range( nm)

Resolution( nm)

Slit(μm)

SR100Z-G21

200~1100

2.2nm

50μm

1.5nm

25μm

1.0nm

10μm

SR100Z-G23
SR100Z-G24

200~875

350~1025

1.6nm

50μm

1.0nm

25μm

0.7nm

10μm

SR100Z-G28

200~345

0.35nm

50μm

0.2nm

25μm

0.14nm

10μm

SR100Z-G25

532~720(4900cm-1*)*

13cm-1

50μm

SR100Z-G26

638~830(3200cm-1)*

10cm-1

25μm

SR100Z-G27

785~1080(3200cm-1)*

11cm-1

50μm

Note:The*are primarily designed for Raman applications, with the corresponding Raman.

Technical Characteristics:

  • High sensitivity: 78% peak quantum efficiency, UV band optimization
  • High resolution: Realize resolution <1.0nm@25um (200~875nm)
  • High flexibility: 200nm~1100nm, compatible with multiple interfaces including USB3.0, RS232 and RS485

Typical Applications:

  • Detect absorption, transmittance and reflection Spectrum

  • OEM product module: Fluorescence spectrum, Raman spectrum,etc.

High Sensitivity Fiber Optic Spectrometer 2048*64 Effective Pixel Size and 14*14 mu m Pixel Size Fiber Interface Free Space

Company Introduction:

JINSP Company Limited, abbreviated as "JINSP", is a professional supplier with over 17 years of experience in spectral detection technology products, including Raman, FT-IR, LIBS technologies, etc. After 17 years of technology accumulation, the company’s core key technologies have reached the international leading position at the level, and the cumulative number of patent applications exceeded 200.

In addition to its main headquarters located in the bustling city of Beijing, JINSP has established a fully owned subsidiary manufacturing facility situated in the province of Jiangsu, China.

JINSP Company received ISO9001:2015, ISO14001:2015, and ISO45001:2018 certifications. JINSP can provide required certifications, such as certification by the Ministry of Public Security or National Institute of Metrology, Environmental Level Certification, IP Level Certification, CE Certification, Transport Identification Report, EU ECAC certification, German ICT Security Testing, etc.

High Sensitivity Fiber Optic Spectrometer 2048*64 Effective Pixel Size and 14*14 mu m Pixel Size Fiber Interface Free SpaceHigh Sensitivity Fiber Optic Spectrometer 2048*64 Effective Pixel Size and 14*14 mu m Pixel Size Fiber Interface Free SpaceHigh Sensitivity Fiber Optic Spectrometer 2048*64 Effective Pixel Size and 14*14 mu m Pixel Size Fiber Interface Free Space

FAQ

Q1:This is the first time I use,is it easy to operate?

A1:We will send you manual and guide vedio in English,it can teach you how to operate the spectrometer.Also our technicians will offer professional tecnical opearation meetings.

Q2:Can your offer a operation traning?
A2:Your technicians can come to our factory for a training. Jinsp engineers can go to your place for local support
( installation , training, debugging, maintenance ).

Q3:What's your website?
A3:You can visit:www.jinsptech.com

Q4:What about your quality assurance?

A4:We have a quality inspection team. All goods will go through quality inspection before shipment. We can send you pictures for inspection.
