Low Temperature Coefficient High Precision Resistors Metal Film Resistors 10~2MΩ
Low Temperature Coefficient High Precision Resistors Metal Film Resistors 10~2MΩ
Specifications
Brand Name :
TYOHM
Model Number :
RN
Place of Origin :
China
MOQ :
5K
Price :
Please contact us for details
Payment Terms :
T/T
Supply Ability :
Depending on the specific circumstances, it generally takes 5-7 work days to complete
Delivery Time :
7-10 work days
Packaging Details :
T/B
Resistance Value :
10~1MΩ ； 10~2MΩ
Resistance Tolerance :
±1% ( F ) or ±0.5% ( D )
Resistance Temperature Coefficient :
±25ppm/°C、±50ppm/°C、±100ppm/°C
Insulation Resistance :
10,000MΩ ( DC 100V or 500V megger )
Terminal Strength :
1kg ( No evidence of mechanical damage )
Nonflammability :
16 times of rated wattage for 5 min. (RN 1W & RN 1WL) ( not flamed )
Description
High-Precision Low Temperature Coefficient Metal Film Resistors

1. High precision tolerance: ±0.25%, ±0.5%, ±1%, ±5%

2. Exceptional temperature stability with low noise characteristics

3. Superior reliability for demanding applications

4. Special 0.1%/25ppm option available (case by case)

Low Temperature Coefficient High Precision Resistors Metal Film Resistors 10~2MΩ

Product Overview

Precision metal film resistors are high-performance resistive components designed for high-precision, high-stability circuits.

This series utilizes advanced vacuum deposition technology to form a uniform metal film layer on a high-purity ceramic substrate, achieving low temperature coefficients (25ppm, 50ppm, 100ppm) and high resistance tolerances (±0.25%, ±0.5%, ±1%, ±5%).

These products exhibit excellent temperature stability and low noise characteristics, maintaining stable electrical performance even in harsh environments, making them suitable for instrumentation, precision control, and measurement circuits.

Product Technical Specifications
Item Parameter Description
Product Name Precision Metal Film Resistor
Power Range 1/8W ～ 2W
Resistance Range 10Ω ～ 2MΩ
Resistance Tolerance ±0.25%, ±0.5%, ±1%, ±5%
Temperature Coefficient ±25ppm, ±50ppm, ±100ppm
Special Version 0.1% / 25ppm (Customizable)
Operating Voltage 50V ～ 500V
Operating Temperature Range -55°C ～ +155°C
Noise Level Extremely Low Noise
Reliability Excellent long-term stability, extremely low drift
Low Temperature Coefficient High Precision Resistors Metal Film Resistors 10~2MΩ
Product Performance Advantages

High Precision & Low TCR
Ensures stable resistance over a wide temperature range, suitable for high-precision signal processing circuits.

Low Noise Design
Utilizes metal film technology to significantly reduce resistor noise and optimize signal purity.

Superior Reliability
Maintains excellent electrical performance under long-term operation and environmental stress, with extremely low drift rate.

Flexible Tolerance Options
Offers multiple combinations of precision and temperature coefficients to meet diverse design requirements.

Applications

Precision Metal Film Resistors are widely used in:

  • Precision Instruments
  • Medical & Test Equipment
  • Audio & Signal Processing
  • Industrial Automation
  • Calibration & Reference Circuits
