Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker
Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker
Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker
Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker
Specifications
Brand Name :
CVR
Model Number :
CV-3
Certification :
CE,RoHS
Place of Origin :
Guangzhou China
MOQ :
2 Pieces
Price :
Negotiation
Payment Terms :
D/A, D/P, L/C, Western Union
Supply Ability :
1000 Pieces Per Month
Delivery Time :
5--8 Work Days
Packaging Details :
Carton Box & Flight Case
Model Number: :
CV-3
Type :
Three Way Full Range System
Power: :
2000W(RMS)4000W(PEAK)
Input connectors: :
2-Neutrik NL4
Size :
2X15" woofers
Finish :
Black Paint
Description

Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker


Our Unique Advantage:

Small order accept

  • Green Paint, low pollution
  • Flat aluminum wire for the woofer
  • All are textured, durable birch plywood
  • Plug is Neutrik, endure repeatedly plug
  • Import loudspeaker cone, good elasticity for woofer


Package and Delivery:

  1. --Carton or flycase
  2. --At buyers' option



DESCRIPTION and APPLICATION:

The ultra-compact CV-3 is a unique, innovative three-way, full range system. CV-3 is equipped with two 15＂ wave horn loading woofers,one 8＂wave horn loading neodymium driver and one 3＂titanium compression driver optimally splayed for smooth, powerful, mid-long throw wide coverage. Extremely versatile CV-3 blends pleasing aesthetics, uncompromising technical excellence with ease of installation to provide a high quality loudspeaker system to suit installed sound requirements of varied sizes venues such as bars, night clubs, conference centers, stadiums, arenas, etc.

ModelCV-3
TypeTree-way full range system
Frequency Response45Hz-18kHz±3dB
Power handling1600W(RMS)3200W(PEAK)
Sensitivity105dB(1W@1M)
Max@S.P.L135dB(PEAK/1M)
LF section15"(380mm) woofer 100mm
(4in)coil
MF section8"(200mm) neodymium MF
65mm(2.75in)coil
HF section3"compression driver with
75mm titanium diaphragm
Nominal impedance4 ohm
Output section3-channel
Dispersion pattern60°H×40°V
Surface finishBlack paint
Speaker cables1(+)1(-)
Input connectors2×NL4MP speakon
Dimensions490×1210×540mm(W×H×D)
Package dimensions560×1280×610mm/0.43cbm
EnclosurePlywood
Net weight71kg
Gross weight76kg



CVR PRO AUDIO Exclusive area:
Japan, Korea, Peru, USA,Ghana,Uganda,Nigeria,Combodia
USA Address:2012 TRANQUILITY LANE,LEAGUE CITY, TX 77573,USA
Japan Address: 329 AOKI YUASA-TOWN ARIDA-GUN, WAKAYAMA-prefecture
Korea Address:408,Onnuriplaza,128-2,Goean-dong,Sosa-gu,Bucheon-si,Kyungki
Ghana Address:No.9,5th Circular road,Labone Accra
Peru Address:Jr.paruro 1359 tda.159 Lima
Uganda Address: Plot 1175A Mukalazi Road, Bukoto Kampala Uganda. P.O BOX 23217Kampala
Nigeria Address: T. I. REWARD BLOCK, ELECTRONICS MARKET ONITSHA, ANAMBRA STATE.
Combodia Address: #288D Mao Tse Tong Blvd., Sangkat Tumnup Teok, Khan Chamkarmon, Phnom Penh.

CVR Audio is looking for more distributors,please email us for more details information.
