Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
Specifications
Brand Name :
TY
Model Number :
TY0002C05
Certification :
ISO/TS 16949: 2009
Place of Origin :
CHINA
MOQ :
120 PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
10,000 pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Box size: 39*18*6.5cm；Package quantity: 1PCS/box；Carton size: 40.5*39.5*43.5cm；Single carton volume: 0.06959m3；Package quantity: 12box/carton, 12PCS/carton；N.W.: 19.5 KG；G.W.: 20.5 KG
Product name :
Auto dry ignition coils
Material :
PBT / lacquered wire
Color :
Black
Type :
Huge power, compact structure, stable performance
Working environment :
-20℃~120℃
Engine type :
TU5JP4
Description

Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087

1. Specifications:

Item

Technical Parameter

Static values before thermal shock test

Primary resistance (Ω)

0.5±20%

Primary inductivity (mH)

/

Secondary resistance (kΩ)

15±10%

Secondary inductivity (H)

/

High voltage before thermal shock test

Secondary voltage (kV) 1MΩ

＞30

Secondary voltage (kV) 1MΩ 50pF

＞25

“30kV”-test before thermal shock test

30kV over 3 min (open load)

OK

Thermal shock test

50 Zyklen (40min -20℃；20min +120℃)

OK

Static values after thermal shock test

Primary resistance (Ω)

0.5±20%

Primary inductivity (mH)

/

Secondary resistance (kΩ)

15±10%

Secondary inductivity (H)

/

High voltage after thermal shock test

Secondary voltage (kV) 1MΩ

＞30

Secondary voltage (kV) 1MΩ 50pF

＞25

“30kV”-test before thermal shock test

30kV over 3 min (open load)

OK

2. Description:

  • Adopts high-temperature resistant lacquered wires and high silicone steel sheets and imported epoxide resin for capsulation
  • Can be used in the temp of -20℃~120℃
  • Prevent water, dust and shaking
  • Owns a long life, huge power and stable performance

3. Applications:

Applicable Brand

Applicable car

OEM

PEUGEOT

307 1.6L(2004~now)

206 1.6L(Dec, 2012~2009)

207 1.6L(2009~now)

308 1.6L(Jan, 2010~now)

408 1.6L(Jan, 2010~now)

597056

96213086

5970.56

Citroen

Elysee 1.6L(Jun, 2001~now)

C2 1.6L(Oct, 2006~now)

Picasso 1.6L(Jan, 2007~now)

Jaquar 1.6L(2008~now)

597056

9621308680

SAGEM

2526087

ALEO

245086

BERU

2S241

Dry Car Ignition Coil Peugeot 597056 / 96213086, Citroen 597056 / 9621308680, SAGEM 2526087
