64 Nozzles Cashew Sorting Machine SWIR Cashew Nut Grading Machine
64 Nozzles Cashew Sorting Machine SWIR Cashew Nut Grading Machine
Specifications
Brand Name :
PHOENIX
Model Number :
Monarch VGN SWIR
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
Monarch VGN1
Chute :
1
Air Nozzle :
64
Air Pressure (MPa) :
0.6~0.8
Description
Monarch VGN SWIR Sorter Dual-band SWIR Enables Premium Detection To Shell, Defect And FM By Color, Size, Shape And Chemical Composition
Technical Features
Tailored Sorting Solution for Premium Nut Processors
  • Sealed scanning and control boxes provide machine with high-level dust protection
  • Field-proven Dust Control System and Air Cooling System integrated maintains high operation reliability and performance consistency, and minimizes downtime
  • High-capacity vibratory feeder System evenly distributes nuts into a single layer to minimize overlapping
  • Modular design of vertical frame size from 1 to 8 chutes (1/3/5/8) provides processors more flexibility
Premium 4-in-1 Multispectral Inspection System
  • Dual-Band InGaAs-SWIR Camera System
  • High-Resolution RGB Camera System
  • High-Stability Air-Cooled Halogen Lighting System
  • High-Intensity LED Illumination System
  • Premium precision detection to various detects of nuts by color, size, shape and chemical composition or moisture levels for premium nut processors, with distinct advantages compared to traditional RGB visible-light sorting:
  • Deeper defect detection beyond surface-level: hidden mold, insect damage, rancidity that RGB cameras miss
  • Superb removal of shell fragments and pit residues with higher accuracy
  • Better recognition of plastics, stones, glass and metal even if color-matched to nuts
  • Enhanced detection of early-stage mold & aflatoxin invisible to RGB cameras
  • Increased throughput and efficiency with minimal human intervention
High-Performance Ejector System
  • Engineered for enhanced durability, optimized speed and air consumption
  • Accurate rejection and reliable performance at high-capacity sorting
  • Significant reduction in false rejection rate and total cost of ownership
64 Nozzles Cashew Sorting Machine SWIR Cashew Nut Grading Machine
Specifications
Model Chute Air Nozzle Air Pressure (MPa) Air Consumption (L/min) Power (kW) Voltage Dimension (LWH, mm) Weight* (kg)
Monarch VGN1 1 64 0.6~0.8 <800 3.3 220V～50/60Hz 1095×1995×1990 720
Monarch VGN5 5 320 0.6~0.8 <4500 7.8 220V～50/60Hz 2450×1850×1943 1460
Monarch VGN8 8 512 0.6~0.8 <5000 10.7 220V～50/60Hz 3302×2004×2025 1932
