Optical Glass Sorting Machine 220V Mini Sorter Machine VFG Series
Optical Glass Sorting Machine 220V Mini Sorter Machine VFG Series
Specifications
Brand Name :
PHOENIX
Model Number :
VFG AI Optical Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
VFG4
Chute :
4
Air Nozzle :
256
Air Pressure (MPa) :
0.6~0.8
Voltage :
220V ~ 50/60Hz
Power (kW) :
2.4
Air Consumption (m³/min) :
>2.6
Unpacked Weight (kg) :
1500
Description
VFG Series Optical Glass Sorting Machine

VFG has developed a professional, efficient, and stable glass optical sorting solution for the sorting needs of the waste glass recycling industry.

Product Description

The VFG series optical glass sorting machine is suitable for sorting dry and wet materials ranging from 2 to 30mm. It is widely used for the separation of glass, ceramic fragments, fine calcium carbonate particles, slag, and other materials. And it is also equipped with a specialized ai algorithm for glass sorting and a nano-grade wear-resistant structure for enhanced stability.

Core Technologies
  • The full-color camera recognition system can efficiently identify waste glass based on its color, brightness, transparency, and shape characteristics.
  • Enhanced LED light source system can achieve better recognition of target glass fragment features.
  • New structure with ultra dense air volume high-frequency spray valve, making more accurate removal, and lower loss.
  • Closed telephoto design, brand new dust removal system, achieving more stable working performance.
  • The whole machine adopts a brand new system, with a wider sorting range and more efficient operation of glass.
  • Wear resistant devices are added to the parts of the machine that come into contact with materials, greatly improving the service life.
Sorting Applications

Optical Glass Sorting Machine 220V Mini Sorter Machine VFG Series

Specifications
Model Chute Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Unpacked Weight (kg) Dimension (mm)
VFG4 4 256 0.6~0.8 >2.6 220V ~ 50/60Hz 2.4 1500 2200×2215×2000
VFG6 6 384 0.6~0.8 >4.0 220V ~ 50/60Hz 3.5 1930 2200×2800×1995
