RGB Rice Sorter Machine With 64 Nozzles Rice Sorting Machine
RGB Rice Sorter Machine With 64 Nozzles Rice Sorting Machine
Specifications
Brand Name :
PHOENIX
Model Number :
VR RGB Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
,L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
VR1
Chute :
1
Air Nozzle :
64
Air Pressure (MPa) :
0.6~0.8
Air Consumption (L/min) :
<1000
Power (kW) :
0.9
Description
VR RGB Color Sorter (Classic Model)
As a best-selling classic in the field of rice color sorting, this model is equipped with 64 nozzles per channel, delivering stable and reliable performance to meet high-precision sorting demands.
Core Technical Features for Rice Sorting
We provide tailored, cost-effective rice sorting solutions with the following key advantages:
  • Large-Capacity Vibration Feeder: Ensures even single-layer distribution of rice, significantly reducing grain overlap and improving detection accuracy.
  • Sealed Scanning and Control Cabin: Offers comprehensive dust protection to keep core components running stably in a clean environment.
  • Integrated Field-Proven Dust Removal System: Ensures long-term operational reliability and performance stability while minimizing downtime.
  • Modular Vertical Frame Design: Supports flexible channel configuration (8/10/12/14/16 channels), helping processors adapt their production layout to actual needs.
Cost-Effective Tri-in-One Detection System
  • Utilizes a high-resolution RGB camera array and high-brightness LED lighting for clear imaging and true color reproduction.
  • Outstanding detection accuracy capable of precisely identifying various rice defects (based on color, size, and shape):
    • Discolored grains: yellow, red, black/black-spotted grains
    • Diseased and moldy grains
    • Broken and cracked grains
    • Immature (green) grains
    • Foreign materials: husks, straw, stones, glass, plastic, metal fragments, etc.
High-Performance Jet Sorting System
  • Combines excellent durability, high-speed operation, and efficient air consumption.
  • Delivers precise sorting and stable performance even under high-speed, high-capacity conditions.
  • Significantly reduces false rejection rates and effectively lowers the total cost of ownership (TCO).
Intelligent Control and Remote Support
  • 15‑inch Industrial Touch Panel: Features an intuitive multilingual HMI (Human-Machine Interface) with one‑click switching of preset parameters.
  • Comprehensive Remote Support System: Includes remote access and real‑time monitoring, paired with a dynamic performance dashboard.
  • Online Expert Diagnostics: Provides interactive troubleshooting guidance for rapid response to operational issues.
RGB Rice Sorter Machine With 64 Nozzles Rice Sorting Machine
Technical Specifications
Model Chute Air Nozzle Air Pressure (MPa) Air Consumption (L/min) Power (kW) Voltage Dimension (L*W*H) (mm) Weight* (kg)
VR1 1 64 0.6~0.8 <1000 0.9 220V ~ 50/60Hz 1255*2199*2076 680
VR4 4 256 0.6~0.8 <2000 2.9 220V ~ 50/60Hz 2170*2199*2076 1150
VR6 6 384 0.6~0.8 <3000 4.4 220V ~ 50/60Hz 2800*2199*2076 1480
VR8 8 512 0.6~0.8 <4000 5.9 220V ~ 50/60Hz 3430*2199*2076 1840
VR10 10 640 0.6~0.8 <5000 7.3 220V ~ 50/60Hz 4070*2199*2076 2180
VR12 12 768 0.6~0.8 <6000 8.8 220V ~ 50/60Hz 4835*2199*2076 2550
