RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input
Specifications
Brand Name :
Sopto
MOQ :
Negotiable
Payment Terms :
T/T; L/C; Paypal
Fiber Port :
SFP
Power supply :
External 220V AC
Operating temperature :
-40~+85C
Rate :
10/100 ; 10/100/1000
Management :
Optional
POE :
Optional
Description

1 ~ 8 x 10 / 100 or 10 / 100 / 1000Mbps RJ45 Port Industrial Fiber Media converter

The industrial Fiber media converter, which can also be called industrial fiber switch, operating temperature-40 ℃ to + 85 ℃, support wide voltage dual power input, meet IP40 protection degree and EMC industrial grade requirements, DIN rail installation.

Features

● 1 ~ 8 x 10/100 or 10/100/1000Mbps Auto-sensing RJ45 ports

● 1 ~ 4 x SC fiber ports or SFP ports

● POE optional, Max power to15.4W under af standard, 30W under at standard to each PoE port

● 4 KV Ethernet surge protection, adapt to a harsh outdoor environment

● Support Auto MDI/MDIX

● Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard

● IEEE 802.3 100Base-T or IEEE 802.3u 1000Base-TX compliant

● A store-and-forward switching mechanism

● Operating environment temperature:-40 ° ~ 85 ℃

● Management function optional

Applications

● LAN/WAN

● Access Control Systems

● Building and Environmental Control Systems

● Ethernet

RJ45 Port Fiber Media Converter Support Wide Voltage Dual Power Input

Ordering Information

Part No.

Fiber

Port

Port Rate

(Mbps)

Port

No.

RJ45 Rate

(Mbps)

RJ45

No.

 POE Manage-ment

Distance

(km)

Power

Supply

 Temp.
SFP

SPM-E(1X)T4X-PXT

 SFP 100 1 10/100

1~4

optional

 No No -

External

220V AC

 -40~85 ℃

SPM-E2XT4X-PXT

 SFP 100 2 10/100

2~6

optional

 No No -

External

20V AC

 -40~85 ℃

SPM-EE(1X)T4X-PXT

 SFP 100 1 10/100

1~4

optional

 PSE af No -

External

220V AC

 -40~85 ℃

SPM-EE2XT4X-PXT

 SFP 100 2 10/100

2~6

optional

 PSE af No -

External

220V AC

 -40~85 ℃

SPM-E(1X)T2X-PXT

 SFP 1000 1 10/100/1000

1~8

optional

 No No -

External

220V AC

 -40~85 ℃

SPM-E2XT2X-PXT

 SFP 1000 2 10/100/1000

2~8

optional

 No No -

External

220V AC

 -40~85 ℃

SPM-E4XT2X-PXT

 SFP 1000 2 10/100/1000

4~8

optional

 No No -

External

220V AC

 -40~85 ℃

SPM-EE(1X)T2X-PXT

 SFP 1000 1 10/100/1000

1~8

optional

 PSE af No -

External

220V AC

 -40~85 ℃
SPM-EE2XT2X-PXT SFP 1000 2 10/100/1000

2~8

optional

 PSE af No -

External

220V AC

 -40~85 ℃

SPM-EE2XT2X-PXT

 SFP 1000 4 10/100/1000

4~8

optional

 PSE af No -

External

220V AC

 -40~85 ℃

SPM-EM(1X)T2X-PXT

 SFP 1000 1 10/100/1000

1~8

optional

 No Yes -

External

220V AC

 -40~85 ℃

SPM-EM2XT2X-PXT

 SFP 1000 2 10/100/1000

2~8

optional

 No Yes -

External

220V AC

 -40~85 ℃

SPM-EM2XT2X-PXT

 SFP 1000 4 10/100/1000

4~8

optional

 No Yes -

External

220V AC

 -40~85 ℃
SPM-EEM(1X)T2X-PXT SFP 1000 1 10/100/1000

1~8

optional

 PSE af Yes -

External

220V AC

 -40~85 ℃

SPM-EEM2XT2X-PXT

 SFP 1000 2 10/100/1000

2~8

optional

 PSE af Yes -

External

220V AC

 -40~85 ℃

SPM-EEM2XT2X-PXT

 SFP 1000 4 10/100/1000

4~8

optional

 PSE af Yes -

External

220V AC

 -40~85 ℃
1*9 ,SC

SPM-E(1X)T4X-NXXST

1*9 SC

 100 1 10/100

1~4

optional

 No No

20~100

optional

External

220V AC

 -40~85 ℃

SPM-E2XT4X-NXXST

1*9 SC

 100 2 10/100

2~6

optional

 No No

20~100

optional

External

220V AC

 -40~85 ℃

SPM-EE(1X)T4X-NXXST

1*9 SC

 100 1 10/100

1~4

optional

 PSE af No

20~100

optional

External

220V AC

 -40~85 ℃
SPM-EE2XT4X-NXXST

1*9 SC

 100 2 10/100

2~6

optional

 PSE af No

20~100

optional

External

220V AC

 -40~85 ℃

SPM-E(1X)T2X-NXXST

1*9 SC

 1000 1 10/100/1000

1~2

optional

 No No

20~100

optional

External

220V AC

 -40~85 ℃

SPM-E2XT2X-NXXST

1*9SC

 1000 2 10/100/1000

2~6

optional

 No No

20~100

optional

External

220V AC

 -40~85 ℃

SPM-EE(1X)T2X-NXXST

1*9 SC

 1000 1 10/100/1000

1~2

optional

 PSE af No

20~100

optional

External

220V AC

 -40~85 ℃

SPM-EE2XT2X-NXXST

1*9 SC

 1000 2 10/100/1000

2~6

optional

 PSE af No

20~100

optional

External

220V AC

 -40~85 ℃
