YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS
Specifications
Ignition Type :
CDI
Engine Type :
Single cylinder, air-cooled, four-stroke
Price :
Negotiable
Max. Torque :
11.3/6500(N·m/r/min)
Packaging Details :
SKD 96PCS/40HQ，CKD 138PCS/40HQ
MOQ :
96PCS
Displacement :
162cc
Rear Braking :
Drum brakes
Place of Origin :
Chongqing, China
Front Braking :
Disc brakes
Start System :
Electric kick start
Model Number :
YH150GY-13
Supply Ability :
Customized
Max. Power :
8.8/8000(kW/r/min)
Delivery Time :
45 work days
Engine :
CG150
Payment Terms :
T/T
Brand Name :
OEM
MOQ :
40HQ
Description

Description:

CG150 engine, Youli Keihin carburetor, maintenance-free battery, straight front shock absorber, single rear shock absorber without cradle, ordinary instrument, front and rear mesh wheels, deep-tooth tires (front 3.00-21, rear 4.10-18), reinforced square tube flat fork, aluminum alloy muffler, front disc brake, rear drum brake, aluminum alloy rear handrail. Classic diamond rearview mirror.

Specifications:

Item

Parameter

Dimensions (Length x Width x Height)

2090×900×1230mm

Seat Height

890mm

Wheelbase

1360mm

Minimum Ground Clearance

285mm

Maximum Load

150kg

Steering Angle

38

Side Stand Tilt Angle

13

Ride Capacity

2 Person

Dry Weight

118kg

Fuel Tank Capacity

11.5L

Front Braking System

Disc brakes

Rear Braking System

Drum brakes

Front Tire Size

90/100-21

Rear Tire Size

120/90-18

Battery Size

12V/6.5Ah

Engine Type

Single cylinder, air-cooled, four-stroke

Engine displacement

162

Bore x stroke

62×53

Compression ratio

9.0:1

Maximum power

8.8/8000(kW/r/min)

Maximum torque

11.3/6500(N·m/r/min)

Maximum speed

90km/h

Start-up acceleration

14S

Overtaking acceleration

13S

Lubrication method

Pressure, Splash

Oil volume

1.1L

Clutch type

Multi-plate wet clutch, manual

Ignition method

CDI

Spark plug

A8RTC

Starting method

Electric kick starter

Transmission method

Chain drive

Final gear ratio

15:43


Product Showcase:

YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS

YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS


YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS

YH150GY-13 Off-Road 150cc Air-Cooled Honda Suzuki Yamaha Bajaj TVS





Packaging parameters:

SKD

CKD

Package Dimensions (Length x Width x Height)

1830×460×840mm

1350×760×380mm

Gross Weight

136kg

136kg

Quantity

96(40HQ)

138(40HQ)

Frequently Asked Questions:

Q1. About us:

A: Jiangmen Songfeng Import and Export Co., Ltd. is the export arm of our manufacturing facility, Yuanhua Technology Co., Ltd. We provide factory-direct pricing and strict quality control, ensuring you receive competitive products straight from the source.

Q2. Payment Terms:

A: We require 30% deposit to begin production preparation, with the remaining 70% due upon completion before loading.

Q3. Delivery Timeline:

A: Depending on the order quantity, usually around 45 working days

Q4. Customization:

A: We can meet OEM requirements and, with the customer's authorization, use the customer's brand. Displacement and other configurations can be modified upon request.

Q5. After-sales Service:

A: We provide 24-hour online support to resolve quality issues at any time and guarantee the supply of all original spare parts to ensure your worry-free after-sales experience.
