Specifications
Place of Origin :
Sichuan，China
Brand Name :
XBSY
Certification :
USE 18000,USE14000，EAC，CE，ISO9000
MOQ :
1
Packaging Details :
Ply Wood Box,iron box
Delivery Time :
1-2 months
Payment Terms :
TT
Supply Ability :
1000
Price :
Price Negotiable
Model :
LW250 × 1025B
Drive Type :
VFD Intelligent Variable Frequency
Drum Inner Diameter (mm) :
250
Drum Working Length(mm) :
1025
Maximum Drum Speed (r/min) :
5000
Drum Working Speed (r/min) :
≤ 4800
Max. Capacity (m³/h) :
10
Description

Smart VFD Centrifuge: ≤4800 RPM Speed & Touchscreen Interface​​

The LW250×1025B VFD centrifuge uses PLC programming to enable stepless drum speed adjustments (0–4,800 RPM). Operators monitor real-time parameters—torque, bearing temperature, vibration, and differential speed (≤50 RPM)—via a color explosion-proof touchscreen. Ideal for upgrading legacy solids control systems or integrating into smart drilling rigs, this automation reduces human error while optimizing separation efficiency for complex drilling fluids. Weight: 2,500 kg.Achieve unparalleled particle separation with a max drum speed of 5,000 RPM and Fr ≤3,225. The 250 mm drum diameter and 1,025 mm working length enable precise solids control for particles as fine as 2–5 µm. VFD-driven motors (11 kW main, 2,900 RPM auxiliary) adapt instantly to mud density fluctuations in shale gas or HP/HT wells, maintaining >90% barite recovery. Max capacity: 10 m³/h.

4800RPM Vertical Horizontal Decanter Centrifuge With Touchscreen Interface​​

Features
PLC Programming Control - Drum speed can be steplessly adjusted within the design range.
Equipped with color explosion-proof touch screen, real-time view of speed, current, torque, bearing temperature, whole machine vibration, differential speed, etc.
Intelligent control, easy operation, large processing capacity, good effect and low failure rate.

Model LW250 × 1025B
Drive Type VFD Intelligent Variable Frequency
Drum Inner Diameter (mm) 250
Drum Working Length(mm) 1025
Maximum Drum Speed (r/min) 5000
Drum Working Speed (r/min) ≤ 4800
Fr ≤ 3225
Pusher Differential Speed (r/min) ≤50
Max. Capacity (m³/h) 10
Rated Power (kW) (Main Motor) 11kW
Rated Speed (r/min) (Auxiliary Motor) 2900 r / min
Feeding Pump Model Screw Pumps or Centrifugal Pumps
L * W * H (mm) 2480 × 800 × 1675
Weight(Kg) 2500
