Customized BTA Hole Drilling Tool OEM Single Flute Cutting Tool High Performance
Customized BTA Hole Drilling Tool OEM Single Flute Cutting Tool High Performance
Specifications
Brand Name :
ARNOLD
Place of Origin :
China
Certification :
ISO9001:2000
MOQ :
2
Price :
40—300 USD
Packaging Details :
standard packaging
Delivery Time :
7-15day
Supply Ability :
1000000 Piece/Pieces per Month
customized support :
OEM, ODM
Workpiece Material :
Steel, Cast Iron, Aluminum
Cutting Tool Material :
High-speed Steel
Machine Type :
Deep Hole Drilling Machine
Cutting Tool Geometry :
Single Flute
Workpiece Hardness :
Up To 60 HRC
Application :
Deep Hole Drilling
use :
Metal Drilling
Description

Product Description:

BTA Deep Hole Drilling is a method used to drill very deep and straight holes in metal parts, usually when the hole is much deeper than its diameter. It is named after the Boring and Trepanning Association.

In this process, high-pressure coolant flows around the outside of a special drill tube, goes to the cutting area, and pushes the chips (metal pieces) out through the center of the drill. This makes the drilling clean, fast, and accurate.

BTA drilling is often used in industries like oil & gas, aerospace, and hydraulic systems to make deep holes in things like gun barrels, hydraulic cylinders, and machine parts. It works best for hole diameters above 20 mm and is known for high speed and smooth, straight holes.

Features:

Advantages of BTA Deep Hole Drilling
  • High Efficiency: Fast drilling speed, especially for large-diameter deep holes.
  • Excellent Hole Quality: Produces straight, round holes with smooth surface finish.
  • Good Chip Removal: Chips are flushed out through the inside, reducing blockages.
  • High Precision: Better control of hole diameter and alignment.
  • Suitable for Long Holes: Can drill very deep holes (over 100x the diameter).
  • Works on Tough Materials: Handles steel, stainless steel, and alloys well.
  • Stable Process: The rigid tool setup ensures consistent results.

Technical Parameters:

Customized BTA Hole Drilling Tool OEM Single Flute Cutting Tool High Performance

Diameter range(mm)

Intermediate insert

Central insert

Peripheral insert

Guide Pad

215.00-220.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

221.00-226.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

227.00-232.99

TPMX 28**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

233.00-247.99

TPMX 24**R..

TPMX 28**R..

TPMX 24**R..

GPS-18-40-300

248.00-253.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

254.00-258.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

259.00-264.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

265.00-271.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

272.00-275.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

276.00-284.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

285.00-289.99

TPMX 24**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

290.00-293.99

TPMX 28**R..

TPMX 28**R..

TPMX 28**R..

GPS-18-40-300

Applications:

Oil & Gas Industry

Drill collars, casing, tubing, and oil tool components benefit from the precision of BTA deep hole drilling.

Defense & Firearms

BTA deep hole drilling is essential for creating gun barrels, cannon barrels, and military-grade tubes with high accuracy.

Mold & Die Making

Deep guide holes for mold bases and die components are crafted with precision using BTA deep hole drilling technology.

Hydraulic Systems

BTA deep hole drilling is used for creating hydraulic cylinder bores and piston rods with accuracy and efficiency.

Aerospace & Aviation

Long, precise holes in structural and engine parts are achieved through BTA deep hole drilling, meeting the stringent requirements of the aerospace industry.

Heavy Machinery

Machine spindles, rollers, and heat exchanger tube sheets benefit from the precision drilling capabilities of BTA deep hole drilling technology.

Refrigeration & Heat Transfer Equipment

Tube plates and components with many deep holes are efficiently and accurately produced using BTA deep hole drilling for refrigeration and heat transfer equipment.
