Exchangeable Replaceable Tip Drills High Speed Steel Titanium Nitride Coated
Exchangeable Replaceable Tip Drills High Speed Steel Titanium Nitride Coated
Specifications
Brand Name :
ARNOLD
Place of Origin :
China
Certification :
CE/ISO9001:2008
MOQ :
negotiable
Price :
50—300 USD
Packaging Details :
standard packaging
Supply Ability :
1000000 Piece/Pieces per Month
Model Number :
EP-G88112
Drill type :
Indexable Drill Bit, Customized Step Drills, Interchangeable Drills
Material :
High-speed Steel
Function :
A Variety Of Drill Heads Are Available
Coating :
Titanium Nitride
customized :
Oem
Cutting :
2
Suitable for materials :
P、M、K、N、S
Application :
Drilling
Description

Product Description:

The drill body is the main structural part of a drill bit, excluding the cutting edge and the shank. It supports the cutting section, transmits drilling force, and assists in chip removal during operation.

Typically, it includes features such as flutes for chip evacuation, margins for guidance, and a core for strength. In some designs, it also contains coolant channels to improve drilling efficiency and tool life.

Common materials include high-speed steel (HSS), carbide, and coated alloys. The drill body plays a crucial role in maintaining stability, accuracy, and performance during drilling processes.

Features:

Drill Body – Features & Advantages
Key Features

- Spiral Flutes: Efficient chip removal and smooth drilling.

- Strong Core: Ensures structural rigidity and reduces breakage.

- Precision Margins: Improve hole accuracy and reduce vibration.

- Optional Coolant Channels: Enhance heat dissipation in high-speed drilling.

Main Advantages

- Stable Performance: Maintains alignment during drilling.

- High Durability: Made from wear-resistant materials like HSS or carbide.

- Versatile Design: Suitable for various materials and machining environments.

- Improved Productivity: Supports higher cutting speeds and longer tool life.

Technical Parameters:

Exchangeable Replaceable Tip Drills High Speed Steel Titanium Nitride Coated

Order Code

Lc

mm

L4

mm

L5

mm

d

mm

Seat size

Dc

Dc

max

EP-G88112-125-B16

EP-G88112-13-B16

EP-G88112-135-B16

EP-G88112-136-B16

EP-G88112-14-B16

171

171

171

181

181

181

48

16

C

12.50

13.00

48

16

C

13.00

13.50

48

16

C

13.50

13.50

184

184

193

48

16

B

13.51

14.00

193

48

16

B

14.00

14.50

EP-G88112-145-B20

184

193

48

20

B

14.50

14.50

EP-G88112-146-B20

199

210

50

20

A

14.51

15.00

EP-G88112-15-B20

199

210

50

20

A

15.00

15.50

EP-G88112-155-B20

199

210

50

20

A

15.50

15.87

EP-G88112-16-B20

224

236

50

20

1

15.88

17.00

EP-G88112-17-B20

224

236

50

20

1

17.00

18.00

EP-G88112-18-B20

224

236

50

20

1

18.00

18.00

EP-G88112-181-B25

252

267

56

25

2

18.01

19.00

EP-G88112-19-B25

252

267

56

25

2

19.00

19.99

EP-G88112-20-B25

277

291

56

25

3

20.00

21.00

EP-G88112-21-B25

277

291

56

25

3

21.00

22.00

EP-G88112-22-B25

277

291

56

25

3

22.00

22.00

EP-G88112-221-B25

303

316

56

25

4

22.01

23.00

EP-G88112-23-B25

303

316

56

25

4

23.00

24.00

EP-G88112-24-B25

303

316

56

25

4

24.00

24.00

EP-G88112-241-B32

332

350

60

32

5

24.01

25.00

EP-G88112-25-B32

332

350

60

32

5

25.00

26.00

EP-G88112-26-B32

332

350

60

32

5

26.00

26.00

EP-G88112-261-B32

356

373

60

32

6

26.01

27.00

EP-G88112-27-B32

356

373

60

32

6

27.00

28.00

EP-G88112-28-B32

356

373

60

32

6

28.00

28.00

EP-G88112-281-B32

381

397

60

32

7

28.01

29.00

EP-G88112-29-B32

EP-G88112-30-B32

381

397

60

32

7

29.00

30.00

381

397

60

32

7

30.00

30.00

EP-G88112-301-B32

410

427

60

32

8

30.01

31.00

EP-G88112-31-B32

410

427

60

32

8

31.00

32.00

EP-G88112-32-B32

410

427

60

32

8

32.00

32.00

EP-G88112-321-B40

433

456

70

40

9

32.01

33.00

EP-G88112-33-B40

433

456

70

40

9

33.00

34.00

EP-G88112-34-B40

433

456

70

40

9

34.00

35.00

EP-G88112-35-B40

459

481

70

40

9

35.00

36.00

EP-G88112-36-B40

459

481

70

40

9

36.00

36.00

EP-G88112-361-B40

486

507

70

40

10

36.01

37.00

EP-G88112-37-B40

486

507

70

40

10

37.00

38.00

EP-G88112-38-B40

EP-G88110-39-B40

EP-G88110-40-B40

EP-G88110-41-B40

EP-G88110-42-B40

486

435

507

70

40

10

38.00

39.00

455

70

40

10

39.00

40.00

435

463

463

455

70

40

10

40.00

41.00

483

70

40

10

41.00

42.00

483

70

40

10

42.00

42.00
$

Applications:

Application Areas of Drill Body

1. Mechanical Manufacturing

  • Drilling metal components
  • High-precision drilling in CNC machining
  • Used in automotive, machine tools, and industrial equipment production

2. Aerospace Industry

  • Drilling structural parts made of titanium or composites
  • Deep hole drilling with high heat and stability requirements

3. Construction and Structural Engineering

  • Drilling in concrete, brick, and other hard materials
  • Used for installation, reinforcement, or cable passage holes

4. Mold and Precision Machining

  • Drilling mold cavities, cooling channels, and other complex shapes
  • Suitable for small-diameter, high-precision drilling

5. Electrical and Electronics

  • Micro-hole drilling in printed circuit boards (PCBs) or connectors
  • Requires high drilling accuracy and surface finish

6. Oil and Mining Equipment

  • Part of specialized drilling tools such as core drills
  • Operates in high-impact, high-temperature, and high-torque environmentsExchangeable Replaceable Tip Drills High Speed Steel Titanium Nitride Coated
