Specifications
Brand Name :
AIRWOLF
Model Number :
MK16-40
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
Negotiation
Payment Terms :
Western Union, T/T, L/C, Paypal, Credit card
Supply Ability :
2000 pieces per 10 working days
Delivery Time :
1-7 work days
Packaging Details :
Plastic bags, boxes, cartons, Pallets or As customer's requirement
Acting type :
Double acting
Fluid :
Air
Temperature :
-20~70
Port size :
M5*0.8
Description

Multi-mount cylinder MD MK Series AIRTAC Type Air Cylinder MK16/10/15/20/40 MK20X5/10/15/20/25/30/40

Bore size:
6
10
16
20
25
32
Acting type:
MK/MKD/MKJ
Double Acting
MSK/MTK
Single Acting
Fluid:
Air(to be filtered by 40μm filter element)
Operating Pressure:
Double Acting:
0.1~1.0MPa(15~145psi)(1.0~10.0bar)
Single Acting:
0.2~1.0MPa(28~145psi)(2.0~10.0bar)
Proof pressure:
1.5MPa(215psi)
Temperature(℃):
-20~70
Speed rang (mm/s):
Double Acting: 30~500 Single Acting:50~500
Stroke tolerance:
(0~+1.0)
Cushion Type:
Bumper
Port Size:
M5X0.8
PT1/8

Bore size(mm)
Standard Stroke(mm)
Max Stroke(mm)
Allow Stroke(mm)
6
Double Acting:
5 10 15 20 25 30 35
35
40
Single Acting:
5 10 15 20
20
-
10
Double Acting:
5 10 15 20 25 30 35
35
40
Single Acting:
5 10 15 20
20
-
16
Double Acting:
5 10 15 20 25 30 40 50
50
70
Single Acting:
5 10 15 20
20
-
20
Double Acting:
5 10 15 20 25 30 40 50 60
60
80
Single Acting:
5 10 15 20
20
-
25
Double Acting:
5 10 15 20 25 30 40 50 60
60
80
Single Acting:
5 10 15 20
20
-
32
Double Acting:
5 10 15 20 25 30 40 50 60
60
80
Single Acting:
5 10 15 20
20
-

Multi-mount cylinder MD MK Series AIRTAC Type Air Cylinder MK16/10/15/20/40 MK20X5/10/15/20/25/30/40Multi-mount cylinder MD MK Series AIRTAC Type Air Cylinder MK16/10/15/20/40 MK20X5/10/15/20/25/30/40

Quality Standards
The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount, but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance, according to the original quality standards, during warranty with product problems, need confirmation testing by the manufacturer, the supplier to be solved, the demand side due to storage, use, poor maintenance caused by lower-quality product, and not raise objections.

Packaging shipping
1. If order is not big enough, we will provide Door To Door service, we cooperate with UPS,DHL,FEDEX,TNT all year round,we gurantee that the shipping price that we offer to you is the most favorable price among so many suppliers in China.
2. By Air or By Sea through your forwarder is acceptable, if you have no forwarder in China, we also could find you cost-effective forwarder for your reference.

Samples
You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

After-sale service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
