Specifications
Brand Name :
URILIC
Model Number :
90W-36V
Certification :
ISO9001,CE,UL
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
1000 sets per month
Delivery Time :
3 working days after received full payment
Packaging Details :
Plywood
Product Name :
High Efficiency Solar Panels
Power :
90W
Size :
1220*540*3.5mm
Weight :
4.5kg
Number of Cells :
72 pcs
Solar Cell :
125*62.5*0.19mm
Type :
Semi Flexible Solar panels
Usage :
Onboard, Automotive, Tourist car, Golf cart
Description

90W 36V Semi Flexible High Efficiency Solar Panels Most Powerful Solar Panel

Description:

The 90W 36V semi-flexible solar panel is made of tough material, anti-extrusion, light weight, thin thickness, soft and bendable, and good low-light performance. It is widely used in ships, automobiles, tourist vehicles, golf carts, etc.

Product Details:

Model U90M
Peak Power (W) 90±3%
Open circuit voltage (V) 45.0
Peak Voltage (V) 36.0
peak current (A) 2.50
Short-circuit current (A) 2.70
Cell efficiency 18.3%
Rated operating temperature 48±2°C
Working temperature range -40°C- +85°C
Current temperature coefficient 0.1%/°C
Voltage temperature coefficient -0.37%/°C
Power Temperature Coefficient 0.45%/°C
Solar Cell 125*62.5*0.19mm
Number of cells 72 pcs
Size 1220*540*3.5mm
Weight 4.5 kgs
Surface Packaging Transparent ETFE
Sealant Ethylene Vinyl Acetate (EVA)
Border NONE
Junction Box Waterproof Level ≥IP65

Component size chart:

36V 90W Semi Flexible High Efficiency Solar Panels Anti - Extrusion Light Weight

90W-36V-Semi Flexible High Efficiency solar panels Dimensions

Solar Panels Features:

  1. U-shaped structure, frameless, high strengh, not easy to deform, resistant totyphoon hail, trampled and easy to maintain.
  2. Instead of traditional array interval layout. centralized continuouschip installation can increase unit area loading capacity by 50%.
  3. The R Angle design of the module incrases the PV voltage in the morning and evening. Without the traditional frame shielding, the inverter starts early and closes late, increasing the power generation by 3%.
  4. With the function of sound insulation and natural convection cooling ofu-tube, the PV temperature curve can be improved, and the power generation efficiency of the system can be comprehensively improved by more than 5%.
  5. Traditional photovoltaic can only do plane, can be combined with curved plane design: More than one layer of heat insulation and waterproof buildings without waste of surface installation Product, and U-shaped glass building materials, both safety and energy saving aesthetic. A cost two returns: building materials and power generation.
  6. National quality certification and export TUV certification, the vane of green building.
Solar Panel Details Show:
36V 90W Semi Flexible High Efficiency Solar Panels Anti - Extrusion Light Weight

Solar Junction Box

PPO material, IP67.
Quality diode ensures module running safety

Heat dissipation

Long service life

MC4 Cable

Low Iron ultra clear tempered glass with 93% transmittance can resist the hail effectively the protection grade reaches IP65.

Solar Cell

High Efficiency PV Cells
Appearance Consistency
Color sorting ensure consistent appearance on each module
Anti-PID
