Polished Edge Transparent PV Glass UV Resistant Clear Glass Solar Panels 3.2mm
Polished Edge Transparent PV Glass UV Resistant Clear Glass Solar Panels 3.2mm
Polished Edge Transparent PV Glass UV Resistant Clear Glass Solar Panels 3.2mm
Polished Edge Transparent PV Glass UV Resistant Clear Glass Solar Panels 3.2mm
Specifications
MOQ :
10 Square Meters
Price :
USD0.99-USD2.1/SQM
Packaging Details :
strong wooden crates suitable for long-distance ocean transportation
Brand Name :
YIWO
Model Number :
Float Glass
Place of Origin :
Hebei, China
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
1500000 sqm/year
Delivery Time :
5-8 working days
Name :
Transparent PV Glass
UV resistance :
High
Size :
Customizable
Function :
Heat Absorbiing Glass
Edge :
polished
Technique :
Clear Glass, Tempered Glass
Thickness :
3.2mm
Tolerance :
+-0.2mm
Transmittance :
91.7%More
Surface treatment :
Anti-reflective Coating
Scratch resistance :
High
Application :
Solar Panels
Description

Polished Edge Solar Tempered Solar Glass 3.2mm Thickness For Solar Energy Power and Solar Collector

Product Description

Solar tempered glass is a safety-enhanced, optically optimized glass specifically engineered for photovoltaic (PV) modules. It is produced via a thermal tempering process—heating float glass to ~600-700°C and then rapidly quenching it—creating high surface compressive stress and internal tensile stress. This treatment boosts its mechanical strength by 3-5 times compared to ordinary glass, making it highly resistant to impact, bending, and thermal shock.

As the front cover of PV panels, it serves two core roles:

1. Optical performance: Maximizes sunlight transmittance (up to ≥93% with anti-reflective coating) to improve solar cell energy conversion efficiency.
2. Protection & safety: Shields internal solar cells from harsh outdoor conditions (UV radiation, extreme temperatures, humidity, sandstorms) and breaks into small, blunt-edged fragments if shattered, ensuring operational safety.Widely compliant with international standards (EN 12150, IEC 61215), it’s a foundational material for all PV

Specification

Name
 Solar panel tempered glass
Thickness 2mm,2.5mm,3.2mm,4mm
Size 2272X1128, customizable by request
Further Process cleaning, cutting, rough grinding, hole, tempered, package etc.
Surface Mistlite single pattern or ultra clear
Solar Transmittance 91.7%More
Usage It is widely used as solar power generator, water heater, solar panel greenhouse
Tolerance(mm) of thickness ±0.2
Payment Terms 30% T/T in advance, and balance before shipment;L/C;T/T;Paypal
Packing 1.Anti-fungicide paper interlayer between two sheets,wooden crates with strong bottom plank
2.In strong wooden crates suitable for long-distance ocean transportation, with fumigation and CO.
3.Could pack well according to customer's requirement
Feature:
Solar tempered glass integrates core advantages tailored for photovoltaic (PV) applications, combining mechanical durability, superior optics, and environmental adaptability to meet the long-term operational demands of solar power systems:

1. Exceptional Mechanical Strength
Processed via thermal tempering (rapid heating + quenching), it achieves 3-5 times higher strength than ordinary float glass. Highly resistant to impact, bending, and thermal shock, it can withstand hail, sandstorms, and accidental collisions in outdoor environments.
2. Safety-Optimized Shatter Behavior
When broken, it fragments into small, blunt-edged pieces (instead of sharp shards), minimizing risks to personnel, equipment, and property—critical for rooftop, public, and large-scale PV installations.
3. High Optical Transmittance
Optically refined (especially with anti-reflective (AR) coating), it delivers light transmittance of ≥93%, effectively reducing solar energy reflection and maximizing photon absorption by solar cells to boost PV module efficiency.
4. Superior Weather Resistance
Withstands extreme environmental conditions: -40°C to 85°C temperature fluctuations, long-term UV radiation, high humidity, salt spray (coastal areas), and sand erosion (deserts), ensuring stable performance for 25+ years.
5. Compliance with International Standards
Meets strict global certifications such as EN 12150 (tempered glass safety), IEC 61215 (PV module reliability), and ASTM E903 (optical performance), guaranteeing compatibility and quality for global PV projects.
6. Customizable for Diverse Scenarios
Available in various thicknesses (3.2mm, 4mm, etc.), sizes, and surface treatments (AR coating, anti-soiling coating), adaptable to BIPV, floating solar, portable devices, and other special PV applications.
Product Pictures:
Polished Edge Transparent PV Glass UV Resistant Clear Glass Solar Panels 3.2mmPolished Edge Transparent PV Glass UV Resistant Clear Glass Solar Panels 3.2mm
Packaging & Delivery

Packaging Details

1. Anti-fungicide paper interlayer between two sheets,wooden crates with strong bottom plank
2. In strong wooden crates suitable for long-distance ocean transportation, with fumigation and CO.
3. Could pack well according to customer's requirement

Delivery Time: Shipped in 10 days after payment
