Mono P-Type Solar Powered Generator Positive Power Tolerance 1755*1038*30mm
Mono P-Type Solar Powered Generator Positive Power Tolerance 1755*1038*30mm
Specifications
Brand Name :
Purple Horn
Certification :
ISO
Place of Origin :
China
MOQ :
Negotiatble
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Delivery Time :
20days
Packaging Details :
carton,pallet,full container
Cell type :
Mono P-Type,166*166(±1)mm,120(6*20)Half-Cut Cells
Dimension :
1755*1038*30mm
Weight :
20kg
Packing info :
40HQ(26PLTS,936PCS)
Maximum System Voltage :
1500VDC
Maximum Series Fuse Rating :
20A
Description
MONO-FACIAL MODULE RS2-350~375M-E3
P-Type /Positive power tolerance of 0~+3%/Max module efficiency 20.59%
Suitable for ground power plants and distributed projects
Advanced module technology delivers superior module efficiency
·Gallium-doped Wafer·Non destructive cutting ·MBB half-cut
Excellent power generation performance
·Excellent IAM and Weak light response ·Low temperature ratings
·0.55% linear Power decline
High module quality ensures long-term reliability
·Strict selected material ·Advanced technology ·Leading standard
Ultra-hydrophilic self-cleaning coating techniques
Mono P-Type Solar Powered Generator Positive Power Tolerance 1755*1038*30mmMono P-Type Solar Powered Generator Positive Power Tolerance 1755*1038*30mm
Electrical Characteristics STC RS2-350M-E3 RS2-355M-E3 RS2-360M-E3 RS2-365M-E3 RS2-370M-E3 RS2-375M-E3
Maximum Power (Pmax) 350W 355W 360W 365W 370W 375W
Power Tolerance 0~+5W 0~+5W 0~+5W 0~+5W 0~+5W 0~+5W
Module Efficiency 19.21% 19.49% 19.76% 20.04% 20.31% 20.59%
Maximum Power Current (Imp) 10.58A 10.64A 10.70A 10.76A 10.82A 10.89A
Maximum Power Voltage (Vmp) 33.00V 33.30V 33.60V 33.90V 34.20V 34.40V
Short Circuit Current (Isc) 11.01A 11.09A 11.17A 11.25A 11.32A 11.41A
Open Circuit Voltage (Voc) 40.50V 40.70V 40.90V 41.10V 41.30V 41.50V

Values at Standard Test Conditions STC(AM1.5, Iradiance 1000W/m.Cel Temperature 25°℃)

Electrical Characteristics NOCT RS2-350M-E3 RS2-355M-E3 RS2-360M-E3 RS2-365M-E3 RS2-370M-E3 RS2-375M-E3
Maximum Power (Pmax) 263W 267W 271W 275W 279W 283W
Maximum Power Current (lmp) 8.48A 8.54A 8.60A 8.65A 8.71A 8.77A
Maximum Power Voltage (Vmp) 31.10V 31.30V 31.50V 31.80V 32.00V 32.20V
Short Circuit Current (Isc) 8.96A 9.00A 9.06A 9.10A 9.16A 9.23A
Open Circuit Voltage (Voc) 37.70V 38.00V 38.30V 38.60V 38.90V 39.10V

NOCT, lrradiance of 800W/m² AM1.5,Ambient Temperature 20°C, wind Speed 1m/s.
