9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof
9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof
9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof
9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof
9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof
9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof
Specifications
Brand Name :
ALLIN
Model Number :
AYHC350-3609BB60
Certification :
CE TUV
Place of Origin :
Hebei
MOQ :
1 piece
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Price :
$0.25-0.28/Watt
Supply Ability :
1.2GW per year
Delivery Time :
5-8 work days
Packaging Details :
In Protective Corner/Carton/Pallet; Per pallet: 31 + 31 pcs; Per 40'GP container: 806 pcs; Or according to customer's request.
Panel Power :
350W 365W
Panel Type :
Half Cell
Oem Order :
Acceptable
Cell Size :
166*83mm
Cell Type :
9BB Mono
Cell Orientation :
120pcs (6*20)
Panel Specification :
1765*1048*35 mm
Junction Box :
≥IP65
Frame :
Anodized Aluminium Alloy/silver, black, golden, or as per your request
Front Glass :
Low iron, Tempered Glass, High Transmission, thickness 3.2mm or 4.0mm
Backsheet Color :
transparent, white, black, blue, etc.
Cable :
Diameter 4mm2, length 900mm or customized
Connector :
MC 4 compatible
Warranty :
12 months
Panel Efficiency :
18.5%
Description

9BB MBB 350W 365W 120Cells Half Cell PV Solar Power Panel For Solar Roof

1. Product Description

1). Anti-reflective and anti-soiling surface reduce power loss from dirt and dust;

2). Outstanding performance in low-light irradiance environments;

3). Module contains element but does not supply power to external load&has bypass diode for array shading protection;

4). Positive power tolerance:0+3%;

5). 100% EL double-inspection ensures modules are defects free;

6). Modules binned by current to improve system performance;

7). Potential induced Degradation(PID) Resistant;

8). Excellent mechanical load resistance: Certified to withstand high wind loads(2400Pa)and snow load(5400Pa).

2. Mechanical Data

Cell Type

166*83mm mono

Cell Orientation

120pcs (6*20)

Module Dimensions

1765*1048*35 mm

Glass

Low iron, Tempered Glass, High Transmission, thickness 3.2mm or 4.0mm

Backsheet color

transparent, white, black, blue, etc.

Frame Material/Color

Anodized aluminum alloy/silver, black, golden, or as per your request

Junction Box

Protection class≥ IP65

Cable

Diameter 4mm2, length 900mm or as per your request

Connector

MC 4 compatible connector


9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof
9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof

3. Electrical Characteristics

Maximum output power(Pmax/W)

350-365

Maximum power voltage(Vmp/V)

38.94

Maximum power current(Imp/A)

8.99

Open circuit voltage(Voc/V)

47.35

Short circuit current (Isc/A)

9.49

Module efficiency (%)

18.0

Operating Temperature

-40℃~+85℃

Maximum System Voltage

1000V

STC: Irradiance 1000W/m², Module Temperature 25°c, Air Mass 1.5

4. Temperature Characteristics

Temperature coefficient (Pm) -0.400%℃

Temperature coefficient (Voc) -0.320%℃

Temperature coefficient (Isc) 0.050%℃

NOCT (Nominal Operating Cell Temperature) 41±3℃

5. Warranty

Linear perfoemance warranty:

10-year limited warranty of materials and workmanship;

25-year limited warranty of 80% power output.

6. Why choose us

1. All of our products have CE certification,ISO9001:2008,RoHS.

2. We have our own factory,the selling prices is competitive.
3. Prompt delivery and good after-sale services.
4. 80% new materials for production and superior quality.
5. Professional engineer designers.
6. Concurrently engaged in relative solar power system products such as solar panel, solar controller, Inverter , sealed lead acid battery, combiner box, etc.
7. All products supplied by our company will have efficient, high quality and satisfactory after-sale service!

Contact Fay to get what your favorite!

7. Packing & Delivery

In Protective Corner/Carton/Pallet

Modules per pallet: 31 + 31 pcs

Modules per 40'GP container: 806 pcs

or according to customer's request .

Transportation mode according to the shipment volume and customer requirements: sea transportation, China Europe train and air transportation can be used.

9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof

9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof

9BB MBB 350W 365W Photovoltaic Solar Panels 120 Half Cell For Solar Roof

8. FAQ

Q1: What's the warranty of the products?

A:Quality warranty for 12 months; parts will be shipped free during warranty period.

Q2: Can I do OEM?

A:Of course, you can request OEM service.

Q3 :What's your delivery time?

A:Within 10 days after receive advanced payment.

Q4: What's the MOQ? ( Minimum Order Quantity)

A:1 piece.
