6kW Vertical Stackable All-in-One ESS – 5.12kWh to 10.24kWh LiFePO₄

Floor-Standing | Expandable | Pure Sine Wave | 9kW PV Input | 8,000 Cycles

Part 1 – Overview & Features

Product Introduction

The 6kW Vertical Stackable All-in-One ESS is a sleek, integrated energy storage system combining a 6kW hybrid inverter with a 51.2V LiFePO₄ battery (100Ah or 200Ah). Designed for residential and light commercial use, it powers household appliances such as TVs, air conditioners, and lighting — all from a single, space-saving vertical unit.

With its stackable, expandable design, you can start with 100Ah and add a second battery module later to double your capacity to 200Ah (10.24kWh). The system features a built-in BMS, pure sine wave output, and multiple communication protocols for seamless integration with solar PV and grid power.

Key Features

• All-in-One Vertical Design – Inverter and battery integrated in one slim, floor-standing unit.

• 6kW Rated Output – 6KVA / 6KW, handles most household appliances.

• Stackable & Expandable – Start with 100Ah (5.12kWh), expand to 200Ah (10.24kWh).

• LiFePO₄ Battery – Safe, stable, and long-lasting lithium iron phosphate chemistry.

• 8,000+ Cycle Life – Designed for over 10 years of reliable performance.

• Built-in BMS – Full protection against overcharge, over-discharge, overcurrent, and temperature extremes.

• Pure Sine Wave Output – Clean power safe for sensitive electronics.

• High PV Input – Up to 9kW solar input, 120A max PV charging current.

• Wide MPPT Range – 60–500Vdc, compatible with most solar configurations.

• Multiple Communication Ports – RS232 / RS485 / CAN for seamless inverter and battery integration.

• AC/DC Priority Output – Flexible energy management based on your preferences.

• Fast Transfer Time – 10ms (PC) / 20ms (household) for uninterrupted backup.

• Easy Installation – Floor-standing design with no complex wiring required.

• LCD Display – Real-time monitoring of system status and battery level.

Part 2 – Key Specifications (Table)

Inverter Specifications

Battery Specifications

Part 3 – Details & Convenience

Vertical, Stackable, Expandable — Built for Easy Installation

The 6kW Vertical Stackable ESS is designed for maximum convenience and flexibility:

• Floor-Standing Vertical Design – Slim, space-saving profile that fits neatly into garages, utility rooms, or basements.

• Stackable Battery Modules – Start with 100Ah and add a second module to reach 200Ah (10.24kWh) — no need to replace the entire system.

• Easy Installation – No complex wiring or wall-mounting required; simply connect and power up.

• Built-in LCD Display – Real-time monitoring of battery SOC, input/output power, and system status.

• AC/DC Priority Output – Choose whether to prioritize solar, battery, or grid based on your energy strategy.

• Multiple Communication Ports – RS232, RS485, and CAN for seamless integration with inverters and monitoring systems.

• Built-in BMS – Intelligent battery management for safety and longevity.

• Quiet Operation – Suitable for residential environments.

• Expandable Design – Add battery modules as your energy needs grow.

Safety First

• LiFePO₄ Technology – No thermal runaway, no fire risk.

• Multi-Layer Protection – Overcharge, over-discharge, overcurrent, short-circuit, and temperature protection.

• Rigorous Testing – Passed short circuit, overcharge, over-discharge, damp heat, and thermal shock tests.

• IP21 Protection – Suitable for indoor installation.

• Vibration & Shock Resistant – Designed for safe transport and installation.

Part 4 – Application Scenarios

Where Can You Use It?
