Ip65 A Grade Single Glass Solar Cell Panel 445W
Ip65 A Grade Single Glass Solar Cell Panel 445W
Ip65 A Grade Single Glass Solar Cell Panel 445W
Ip65 A Grade Single Glass Solar Cell Panel 445W
Ip65 A Grade Single Glass Solar Cell Panel 445W
Ip65 A Grade Single Glass Solar Cell Panel 445W
Ip65 A Grade Single Glass Solar Cell Panel 445W
Ip65 A Grade Single Glass Solar Cell Panel 445W
Specifications
Brand Name :
SUNTECH
Model Number :
STP445S-B72
Certification :
TUV SGS
Place of Origin :
CHINA
MOQ :
300000WATT
Price :
Negotiation
Payment Terms :
Western Union, T/T, MoneyGram
Supply Ability :
1000000W
Delivery Time :
14 work days
Packaging Details :
carton
Product name :
solar system panels
Max. power :
345W
Number of cells :
54pcs
Material :
High Efficiency Mono Solar Panels
Backsheet :
White
Description

Ip65 A Grade Single Glass Solar Cell Panel 445W

1. Product Description

2 . Specifications:

Modle BW-SM330M72 BW-SM335M72 BW-SM340M72 BW-SM345M72 BW-SM350M72 BW-SM355M72 BW-SM360M72
Rated Maximum Power at STC 445 35 340 345 350 355 360
Maximum Power Voltage (Vmp) 40.65V 38.5V 38.7V 38.9V 39.1V 39.3V 39.5V
Maximum Power Current (Imp) 10.10A 8.70A 8.79A 8.87A 8.94A 9.04A 9.12A
Open Circuit Voltage ( Voc) 48.9V 46.8V 47.1V 47.3V 47.5V 47.8V 48.0V
Short Circuit Current (Isc) 10.7A 9.15A 9.24A 9.31A 9.38A 9.45A 9.51A
Module Efficiency 20.19% 17.26% 17.52% 17.78% 18.01% 18.31% 18.57%
Power Tolerance 0~+3% 0~+3% 0~+3% 0~+3% 0~+3% 0~+3% 0~+3%
STC: Irradiance 1000W/m², Module Temperature 25°c, Air Mass 1.5
Mechanical Parameters
Cell Type Poly-crystalline 156x156mm (6inch)
No. of Cells 72 (6x12)
Dimension 2034x1000x30mm
Glass 3.2mm, High Transmission, Low Iron, Tempered Glass
Junction Box IP65&IP67 Rated
Output Cable Section Size: 4mm² , Length: 900mm
Frame Anodized Aluminum Alloy
No. of Bypass Diodes 3&6
Connector MC4 Compatible
Working Conditions
Maximum System Voltage DC 1000V(IEC) / 1500V(IEC) / 600V(UL)
Operating Temperature -40°c~+85°c
Maximum Series Fuse 15A
NOCT 45±2°c
Application Class Class II
Temperature Coefficient
Temperature Coefficient of Pmax -0.40%/°c
Temperature Coefficient of Voc -0.30%/°c
Temperature Coefficient of Isc +0.05%/°c

Ip65 A Grade Single Glass Solar Cell Panel 445WIp65 A Grade Single Glass Solar Cell Panel 445WIp65 A Grade Single Glass Solar Cell Panel 445W

Shipping: Within 14 workdays after order confirmed


Ip65 A Grade Single Glass Solar Cell Panel 445W
Ip65 A Grade Single Glass Solar Cell Panel 445W

OUR Services :

1. Rich experience in manufacturing and exporting electric equipment.

2. High quality and competitive price.

3. Strict quality control and excellent after-sales service.

4. Manufacturing according to customers requirements is available.
