Specifications
Model Number :
AS575~605M10-156
Place of Origin :
Anhui, China
Cell size :
182mmx182mm
Type :
PERC, Half Cell, Bifacial, Double-glass, All Black
Panel Dimensions :
2465*1134*35MM
Panel Efficiency :
21.65%
Warranty :
25 Years, 25 Years
Application :
Solar Power System
Product name :
solar PV module
Cell Type :
Mono Solar Cell
Certificate :
CE, TUV, INMETRO,
Frame :
Anodized Aluminium Alloy
Junction Box :
IP68 Rated
Keyword :
Photovoltaic module
Number of Cells :
156 cells
Weight :
30.5KG
MOQ :
1000 watts
Price :
$0.14/watts 1000-9999 watts
Description
Mechanical Data
ELECTRICAL PARAMETERS
ELECTRICAL PARAMETERS
Rated Maximum Power at STC
575W
585W
595W
600W
605W
Open Circuit Voltage (Voc)
51.02
51.28
51.54
51.67
51.8
Maximum Power Voltage (Vmp)
43.04
43.34
43.64
43.79
43.94
Short Circuit Current (Isc)
14.25
14.39
14.53
14.60
14.67
Maximum Power Current (Imp)
13.36
13.50
13.64
13.71
13.78
PV Module Efficiency (%)
20.57
20.93
21.29
21.47
21.65
STC: Irradiance 1000W/m2, Cell Temperature 25°C, Air Mass AM1.5.
*Measuring Tolerance: ±3%.
STC: Irradiance 1000W/m2, Cell Temperature 25°C, Air Mass AM1.5.
*Measuring Tolerance: ±3%.
Layout
156( 6 × 26）
Junction Box
Split junction box, IP67, 3 diodes
Weight
30.5KG
Cable Length
300mm (+) / 300mm（-)
Cable Size
4mm²（IEC)
PV Size
2465×1134×35mm
Packaging
30 pcs / pallet
540 pcs / 40HQ container
