Specifications
Model Number :
AS480-505M10-132
Place of Origin :
Anhui, China
Cell size :
182mmx182mm
Type :
PERC, Half Cell, Bifacial, Double-glass
Panel Dimensions :
2094*1134*35MM
Panel Efficiency :
21.25%
Warranty :
25 Years, 25 Years
Application :
Solar Power System
Product name :
solar PV module
Cell Type :
Mono Solar Cell
Certificate :
CE, TUV, INMETRO,
Frame :
Anodized Aluminium Alloy
Junction Box :
IP68 Rated
Keyword :
Photovoltaic module
Number of Cells :
132 cells
Weight :
26.0KG
MOQ :
1000 watts
Price :
$0.14/watts 1000-9999 watts
Description
ELECTRICAL PARAMETERS
Rated Maximum Power at STC
480W
485W
490W
495W
500W
505W
Open Circuit Voltage (Voc)
45.07
45.22
45.37
45.52
45.67
45.82
Maximum Power Voltage (Vmp)
37.65
37.81
37.97
38.13
38.29
38.45
Short Circuit Current (Isc)
13.65
13.72
13.79
13.86
13.93
14.00
Maximum Power Current (Imp)
12.75
12.83
12.90
12.98
13.06
13.13
PV Module Efficiency (%)
20.21
20.42
20.64
20.85
21.06
21.27
STC: Irradiance 1000W/m2, Cell Temperature 25°C, Air Mass AM1.5.
*Measuring Tolerance: ±3%.
Layout
132( 6 × 22 ）
Junction Box
Split junction box, IP67, 3 diodes
Weight
26.0KG
Cable Length
300mm (+) / 300mm（-)
Cable Size
4mm²（IEC)
PV Size
2094×1134×35mm
Packaging
31 pcs / pallet
682 pcs / 40HQ container
