Specifications
Brand Name :
Amosolar
Model Number :
AS48100/AS48200
Place of Origin :
Anhui, China
Weight :
43.2kg
The charging ratio :
100%
The discharge rate :
80%
Storage Type :
Room temperature storage
Anode Material :
LFP
Application :
Home Appliances, Electric Power Systems, Solar Energy Storage Systems, Home Appliances;House Use
Product name :
Lithium Iron Phosphate Lifepo4 Battery
Capacity :
100Ah 200Ah;5KWH 10KWH
Cycle life :
6000 Times
Voltage :
48V/51.2V
Warranty :
5years
Type :
Li-Ion/lithium/lifepo4
Nominal Voltage :
3.2 Volt
Certification :
CE/RoHS/UN38.3/MSDS
Battery type :
Li-Ion/lithium/lifepo4
Packaging Details :
Cartons and pallets and wooden box
Supply Ability :
500000 Piece/Pieces per Month
MOQ :
5 pieces
Price :
$620.00/pieces 5-499 pieces
Description
Product Description
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
Specification
PERFORMANCE SPECIFICATIONS
Model
AS48100
AS48200
AS51100
AS51200
Cell model/Configuration
3.2V 100Ah/15S1P
3.2V 100Ah/15S2P
3.2V 100Ah/16S1P
3.2V 100Ah/16S2P
Battery Type
LiFePO4(LFP)
LiFePO4(LFP)
LiFePO4(LFP)
LiFePO4(LFP)
Rated Energy (KWH)
4.8KWH
9.6KWH
5.12KWH
10.24KWH
Usable Energy(KWH)
3.84KWH
7.68KWH
4.1KWH
8.2KWH
Max.Charge/Discharge Current(A)
100A/100A
100A/100A
100A/100A
100A/100A
Voltage Range (Vdc)
42-54V
42-54V
44.8-57.6V
44.8-57.6V
Scalability
Up to 15 parallel
Up to 15 parallel
Cycle Life
≥6000cycles@25℃, 0.5C, 80%DOD, 60%EOL
≥6000cycles@25℃, 0.5C, 80%DOD, 60%EOL
Warranty
5 Years (25℃)
5 Years (25℃)
Design Life
10+ Years (25℃/77F)
10+ Years (25℃/77F)
MECHANICAL SPECIFICATIONS
Net Weight( Approx) (KG)
43.2kg
76.8kg
45.1kg
81.6kg
Dimension(mm)(226 lncluding hanger)
480*483*178mm
680*483*178mm
480*483*178mm
680*483*178mm
lnstallation Mode
Stack
Stack
Stack
Stack
Protection
BMS, Breaker
BMS, Breaker
lPGrade
IP20
IP20
BMS
Power Consumption
<2W(Work)<100mW(Sleep)
Monitoring Parameters
System voltage, current, cell voltage, cell temperature, module temperature
SoC
lntelligent algorithm
Communication
RS232-PC,RS485(B)-BAT RS485(A)-Inverter,CAN-Inverter
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature(℃)
Charge: 0℃-55℃; Discharge: -20℃-55℃
Charge: 0℃-55℃; Discharge: -20℃-55℃
Altitude (m)
≤2000
Humidity
≤95%(Non-condensing)
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
Product Paramenters
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
Parallel Function
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
Training and Exhibition
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
Packaging & Projects
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
Supported Brands
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
48V/51.2V 100Ah Lithium Battery Rack Mount 51.2V 200Ah Lithium Ion Cell Battery Perfect
FAQ
A: What are your main products?
We mainly manufacture solar panel , lead acid battery, lithium battery . And we could offer the complete solar system, solar inverter, solar air conditioning system, solar inverter, heat pump etc.

B: Are you a factory or a trading company?
We are a factory with more than ten years of experience in the production of solar energy series products. You are welcome to visit our factory.

C: Can you print our company logo on the nameplate and packaging?
Yes, we can do it according to your design.

D: Can you support OEM and field installation?
Yes, as a professional solar system manufacturer, we can provide customers with OEM and on-site installation, full support and
assistance services.

E: How does your factory conduct quality control?
Quality first. We have a professional QC team to strictly control the quality.

F: What kind of inverters can this product match?
Off Grid and Hybrid inverter , like Deye inverter, Growatt inverter, Goodwe Inverter, Sofar Inverter etc.
