Portable Crawler Drilling Rig Equipment 145KW Rated Power High Efficiency
Portable Crawler Drilling Rig Equipment 145KW Rated Power High Efficiency
Specifications
Brand Name :
SINOWAY
Model Number :
SWCDR500
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
2000 units per year
Delivery Time :
35 days
Packaging Details :
Nude
Engine model :
Cummins 6CTA8.3-C195
Rated power :
145KW
Rated speed :
1900rpm
Drilling capacity(BQ) :
1500m
Drilling capacity(NQ) :
1300m
Drilling capacity(HQ) :
1000m
Drilling capacity(PQ) :
680m
Description

Hot selling Core Portable Crawler Hydraulic Core Drill Rig With CUMMINS Engine 145KW Rated Power

Engine Engine model Cummins 6CTA8.3-C195
Rated power 145KW
Rated speed 1900rpm
Drillingn capacity BQ 1500m
NQ 1300m
HQ 1000m
PQ 680m
Rotator capacity Rated speed 0~1145rpm Two shifts/stepless
Max. Torque 4650N.m
Hold diameter φ121mm
Max. lifting capacity of spindle 150KN
Max. feeding power 75KN
Capacity of main hoist Hoisting force (single wire) 77KN
Steel wire diameter 18mm
Steel wire length 60m
Capacity of Steel wire hoist Hoisting force (single wire) 12KN(Bare drum)
Steel wire diameter 6mm
Steel wire length 1500m
Mast Mast height 12m
Mast adjusting angle 0°~90°
Drilling angle 45°~90
Feeding stroke 3800mm
Slippage stroke 1100mm
Other Weight 13000kg
Overall dimension(L×W×H) 6250x2240x2500mm
Transport way Crawler
Mud pump BW-250
Foot clamp(clamping scope) 55.5~117.5mm(φ154mm)
