KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
KunYou 32000pcs/H Paintball Making Machine with PLC Control
Specifications
Brand Name :
Kunyou
Model Number :
S610PB
Certification :
CE,ISO9001
Place of Origin :
China,Beijing
MOQ :
1 set
Payment Terms :
T/T， L/C,Western Union
Supply Ability :
30 Set/Sets Per Year
Delivery Time :
30-90 days
Packaging Details :
Wood cages
Application :
Paintball Making
Capicity :
32000 Painballs/H
Die Roll :
250X150
Control Mode :
PLC/Touch Screen
Certificate :
CE
Brand :
KunYou
Description

Full Auotmatic High Efficient Paintball Making Machine CE Certificated

Quick Detail

Product Name Large scale paintball making machine Driven Type Electric
Capacity 32000pcs /hour shape round
Application Food, pharmaceutical, paintballl making machine Control PLC

Product Description

S610PB Paintball making machine is suitable for large scale paintball production. The machine adopts independent lubrication single adjustable lubrication, saving production cost for customers.

KunYou 32000pcs/H Paintball Making Machine with PLC Control

Specifically speaking, it has the following characteristics:

  • Dosage deviation:<+1.5%
  • Gelatin ribbon lubrication: paraffin oil or fractionated coconut oil, less than 1kg in 8 hours. Solvent free.
  • Major bearing made in Germany.
  • Capsule brushes are driven by independent motor to prevent the gelatin stuck into the die roll cavity.
  • Separate lubrication system for medicine pump and die roll assembly.
  • Water cooled drum also have air blowers
  • PLC and touch screen control with self-trouble diagnostic.
  • Automatic medicine supply. The system can even alarm when the fill material tank is empty.
  • High accuracy medicine pump. The diameter tolerance of the 20 plungers are less than 0.005mm.

Specification

Model S610PB
Die roll size 150×250mm
Die roll speed 0~5rpm
Max plunging volume per stroke 0~2ml
Plunger numbers 20/24
Overall dimension 2050×1200×1850
Weight of main machine 1900kg
Power consumption 13.5kw
Control mode PLC+Touch Screen
output 32000 pcs/hour

Competitive Advantages

  • Improve the efficiency of production largely
  • Compact and beautiful
  • Reduce the oil consumption
  • Save money for users
  • Low noise, run more smoothly
  • PLC+touch screen

Fully Automatic paintball making machine, Paintball Encapsulation Machine
