Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Pharmaceutical Paintball Making Machine
Specifications
Place of Origin :
China,Beijing
Brand Name :
Kunyou
Certification :
CE,ISO9001
Model Number :
S406
MOQ :
1 set
Packaging Details :
Wood cages
Delivery Time :
20-60 days
Payment Terms :
T/T， L/C
Supply Ability :
30 Set/Sets
Type :
Filling Equipment
Application :
Liquid
Warranty :
1 Year
Material :
304/316L Stainless Steel
Usage :
Pharmacy
Voltage :
3phase 380V
Description
Food / Pharmaceutical Machinery For Softgel / Paintball Maker / 43470 Capsules / Hour
Quick Detail
Product Name Soft capsulate/Paintball making machine Driven Type Electric
Capacity 43470 Capsule /hour, 8#OV
18000 Paintball/hour, 0.68"Ball		 Control Mode Full Automatic
Application Food, pharmaceutical, fish oil making Capsule shape OV, OB,etc

Pharmaceutical Paintball Making Machine

Product Description

S406 soft capsule filling machine is suitable for medium scale production. Soft capsule making machine is used for making soft capsules, such as fish oil soft capsules, Vitamin E soft, Omega-3 and food capsules, etc.

Soft capsule making machine abosorbs advanced technologies at home and abroad, based on a combination of soft capsule production process and the characteristics of the use advanced technology and high quality materials to meet the GMP requirements of well-designed.

Capsule making machine consist of soft capsule machine, sol pot, mould (die roll), capsule conveyor, tumbler dryer, cooling air machine, vacuum pump, drying tray, vacuum mixing barrel and electrical control system and other ancillary equipment.

This machine can be applied to all kinds of drugs, food, cosmetics, oils and hydrophobic substances in the quantitative suspension or paste injection pressure and encapsulated in gelatin membrane, the formation of various sizes in sealing the soft capsules.

Specification
Model S406
Die roll diameter Ф103mm
Die roll length 152mm
Die roll speed 0~5rpm
Plunger numbers 10
Dosage tolerance ± 2%
dimension 880X640X1900mm
weight 900kg
Power consumption 7kw
Control mode PLC+HMI Switch/buttons
Output 8#OV 43470 pcs/hour
Competitve Advantages
  • Good stability
  • Adjustable rotation rate during 0-5rpm
  • Easy to operate and clean, conforming to GMP
  • Compact and beautiful
  • It can be assembled or disassembled with single hand
  • Big air flow
  • Reduce the oil consumption
Product tags

paintball encapsulating machine

,

paintball encapsulation machine

,

paintball machine
