220V Electronic Pick and Place Machine for LED, PCB Max 1200*350mm, 0.02mm Precision
220V Electronic Pick and Place Machine for LED, PCB Max 1200*350mm, 0.02mm Precision
220V Electronic Pick and Place Machine for LED, PCB Max 1200*350mm, 0.02mm Precision
220V Electronic Pick and Place Machine for LED, PCB Max 1200*350mm, 0.02mm Precision
220V Electronic Pick and Place Machine for LED, PCB Max 1200*350mm, 0.02mm Precision
220V Electronic Pick and Place Machine for LED, PCB Max 1200*350mm, 0.02mm Precision
Specifications
Brand Name :
ETON
Model Number :
HT-E8S-1200
Certification :
CE, CCC, SIRA
Place of Origin :
CHINA
MOQ :
1 set
Payment Terms :
T/T
Supply Ability :
50 sets per month
Delivery Time :
30 days after receive the down-payment
Packaging Details :
vacuum adsorption, wooden packing
Warranty :
1 Year
Applicable components :
0402
Name :
SMT Pick and Place Machine
Condition :
100% Original,Brand-new
Weight :
1700kg
Mounting speed :
45000 CPH
Feeders :
28
Speed :
45000chips/h
Description

220V Electronic Pick and Place Machine for led

Machine main features

1)Single module magnetic linear motor multifunctional pick and place machine.

2)Mounting components: LED chip,capacitors,resistors,lens,IC,shaped components,etc.

3)Component: Min.size 0402. Max.height 15mm.

4)Application: power drive. electric board. Lens. DOB bulb. Linear bulb. Household appliance,etc.

Technical Parameters

HT-E8S pick and place machine
PCB PCB length width Max:1200*350mm min:100*100mm
PCB thickness 0.5~5mm
PCB clamping Adjustable pressure pneumatic
O.S. system Windows 7
software R&D independently
display Touch screen monitor

Vision

system

 No.of camera

2sets of imported camera

Vision for the alignment identification,mark correction
Mounting precision 0.02mm(repeat precision)
Mounting height <36mm
Mounting speed 45000CPH
Components space 0.2mm
No.of feeders station 36PCS
No.of nozzles 12PCS
Power 380AC 50HZ
Power consumption 4KW
Transmission direction Both direction
Transmission mode Auto online drive
Electrical control Independent research and development by ETON
Motion control card module 1set Independent research and development by ETON
X,Y,X axis drive way Servo motor+magnetic linear motor control for X,Y,Z axis

220V Electronic Pick and Place Machine for LED, PCB Max 1200*350mm, 0.02mm Precision

Application

220V Electronic Pick and Place Machine for LED, PCB Max 1200*350mm, 0.02mm Precision

E8S-1200 also can mount some complex components:LED, capacitors,resistors,IC,shaped components, etc.

The capacity of E8S-1200 is reach 40000-45000CPH.

Production: DOB, home appliance control boards, power drivers, LED down-lights, LED bulb lights, LED panel lights, etc.

Service

Maintenance period 1 year

One year warranty, during warranty, any parts that need to be repaired and replaced will be free.

Software and hardware lifetime maintenance

Free upgrade software, the software is Reach and developed by ETON, so we support whole lifetime free upgrade updates.

Visit customers regularly and gather information

Visit clients regularly. We attend the different exhibitions in different cities every year, at the same time, we will visit local clients and support our service and collect feedback on customer suggestions in time.

Provide the latest information about technology and equipment

We give professional technology suggestions to our clients. And share the updated news with our clients.

FAQ

1.How is your service?
If you buy our machine,we will send our engineer to your factory to install machine and training freely.


2.What’s the terms of payment? What about the trade term?
T/T is OK. You can choose FOB Shenzhen.


3.How can you make sure we will receive the machine with high quality?
Our team will inspect each batch of machine before delivery, we have certificates of CE,Quality management certificate.


4. What your main customers?
We have exported machine to different countries,such as India,Egypt,Korea,Turkey,Brazil etc.
Such as FSL,ETI,KONKA,OPPLE,MLS are our client,In india such as RK,Surya,skyquad are our client.
