Modular Drawer Design PCB Cleaning Machine Mitsubishi PLC Control
Modular Drawer Design PCB Cleaning Machine Mitsubishi PLC Control
Specifications
Brand Name :
ETON
Model Number :
pcb cleaning machine
Certification :
CCC/CE
Place of Origin :
China
Machine name :
pcb cleaning machine
Machine function :
Cleaning pcb before printer
Description

High quality Online Set Up Before Stencil Printer PCB Cleaning Machine

Features

1. Widely application

  • Suitable for cleaning the board between stencil printer and loader

2. High Performance

  • Modular drawer design
  • Use high-quality cleaning rollers and dust-removing paper wheels to further improve cleanliness
  • High-speed spiral brush to improve the cleanliness of the work
  • Bottom support structure to ensure the contact of the clean surface
  • Dust collection box to prevent the leakage of dirt and affect the environment
  • Mitsubishi PLC control

3. SMT Industry standard connect design

  • Touch screen operation interface design
  • Standard SMEMA interface
  • Three-color light device displays real-time alarm information

Modular Drawer Design PCB Cleaning Machine Mitsubishi PLC Control

Parameter

Model ET-PC-250 ET-PC-330 ET-PC-390 ET-PC-460
Dimension L555xW820xH1350mm L555xW900xH1350mm L555xW960xH1350mm L555xW1030xH1350mm
Board size 50x50-350x250mm 50x50-450x330mm 50x50-530x390mm 50x50-530x460mm
Magazine size L355xW320xH565mm L460xW400xH565mm L535xW460xH565mm L535xW530xH565mm
Process height 900±20mm
Process speed 0-9m/min
Flow direction L→R or R→L
Board thickness 0.4-5mm
Brush rotation 200-1200 RPM
Brush amount Top 2
Brush style Antistatic & high density
Dust removal Top 1
Board support 1
Vacuum clean Dust collection box
ESD removal Both inload / outload
Weight 80kg 90kg 100kg 110kg
Power requirement 220Vac 50/60Hz ,1ph
Air requirement 0.4-0.6 Mpa; Max 30L/min
