GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment
GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment
GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment
GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment
GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment
GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment
Specifications
Brand Name :
GS
Model Number :
GS-LAD2303
Place of Origin :
China
MOQ :
1 PCS
Price :
USD+negotiable+pcs
Payment Terms :
T/T
Supply Ability :
1+pcs+per days
Delivery Time :
1-7 days
Packaging Details :
850*90*180
Model :
GS-LAD2303
Overall dimensions (length * width * height) :
624*78*160
Weight :
6.5KG
Working voltage :
DC 24V
Gas source requirements :
no
Maximum current :
2.5A
Feeding speed :
1.5s/Pcs
Operation panel :
0.96-inch TFT color screen, 80*160 pixels
Material change time :
3min
Channel :
Single channel
Pin bending function :
Bend
Lifting function :
Lifting feeding
Foot cutting function :
Cut off
Straightening function :
Alignment of alignment
Material wire diameter :
0.4-0.7mm(The bending module needs to be replaced when changing the wire diameter)【It is not adjustable. For example, for a 0.6mm module, only 0.6mm iron wire can be drawn】
Jumper span 1 :
5-26mm(Change the length of the fixture when changing the span)【It is not adjustable. For example, for a 16mm span, only a 16mm length fixture can be used】
Jumper span 2 :
The maximum span is 35mm(the arc-shaped deformation of the product will be larger).【It is not adjustable. For example, for a 16mm span, only a 16mm length fixture can be used】
The length of the formed pins :
2.0~5.5mm【Within this range, it can be achieved by replacing the fixture. One fixture can only correspond to a single size】
Description

Jumper Feeder (GS-LAD2303)

The jumper feeder is a component supply device that sends out the coiled copper wires one by one according to a fixed length, cuts them into shape and supplies them to the insertion machine.

GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment

GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment

GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment

GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment

GS-LAD2303 Jumper Feeder 6.5KG Straightening Function for Alignment of Alignment

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
