ZS Feida front-end hook safety buckle

Product Introduction – ZS Feeder Front-end Hook Safety Latch

The ZS Feeder Front-end Hook Safety Latch is a small but essential mechanical part mounted on the front section of ZS series feeders. It is designed to secure the feeder firmly to the SMT machine’s feeder base, preventing accidental detachment or misalignment during high-speed operation.

Key Features:

Enhanced Feeder Stability
Provides a secure mechanical lock to prevent the feeder from shaking, loosening, or lifting during placement.

Tool-free Locking
Features a spring-loaded or snap-fit mechanism that allows for easy mounting and removal without tools.

Durable Material
Made from reinforced plastic or hardened steel to withstand repeated use, vibration, and production stress.

Precision Fit for ZS Feeders
Specifically designed for Yamaha / Hanwha ZS-type feeders, ensuring proper alignment and compatibility.

Applications:

Suitable for 8mm–24mm ZS feeders, depending on version.

Compatible with Yamaha pick-and-place models such as:

YSM10 / YSM20 / YSM20R
Sigma G5 / G5S
Z:TA-R series

Widely used in high-speed SMT production for:

Consumer electronics
Automotive electronics
LED boards
Mobile and communication devices

Purpose:

Prevents the feeder from detaching or vibrating during operation
Ensures consistent component pick-up accuracy
Reduces downtime caused by feeder errors or improper mounting

Related Accessories – ZS Feeder Front-end Hook Safety Latch

1. Feeder Mounting Bracket / Base Plate

The main fixture on the machine where the feeder is attached. The front-end hook latch secures onto this bracket to hold the feeder firmly in place.

2. Locking Pin / Feeder Retaining Pin

A small metal or plastic pin that works with the safety latch to further lock the feeder and prevent lateral movement.

3. Spring Clip / Retaining Clip

Used to maintain tension and secure the latch in position, preventing accidental release during operation.

4. Feeder Front Cover Plate

Some feeder models have a front cover plate that houses or supports the hook latch assembly, protecting it from dust and damage.

5. Latch Actuator / Release Lever

A manual or spring-assisted lever that allows operators to easily disengage the latch for quick feeder removal.

6. Replacement Screws / Fasteners

Small screws or rivets used to attach the safety latch and related parts firmly to the feeder frame.

Related Part Numbers – ZS Feeder Front-end Hook Safety Latch

KJW-M1501-00X — Front-end Hook Safety Latch for ZS feeders (8mm/12mm versions)
KJW-M1502-00X — Front-end Hook Safety Latch for 16mm and 24mm ZS feeders
KJW-M1503-00X — Feeder Mounting Bracket / Base Plate
KJW-M1504-00X — Locking Pin / Retaining Pin for feeder latch
KJW-M1505-00X — Spring Clip / Retaining Clip
KJW-M1506-00X — Feeder Front Cover Plate (with latch support)
KJW-M1507-00X — Latch Actuator / Release Lever
KJW-M1508-00X — Replacement Screws / Fasteners for latch assembly

Note:

The “00X” suffix varies depending on revision or manufacturing batch.
Verify compatibility based on your specific ZS feeder model and tape width.

FAQ Guide – ZS Feeder Front-end Hook Safety Latch

1. What is the purpose of the ZS Feeder Front-end Hook Safety Latch?

It securely locks the feeder onto the machine’s feeder base to prevent accidental detachment or movement during high-speed SMT operation.

2. Which feeder models is it compatible with?

Compatible with ZS-series feeders used on Yamaha and Hanwha machines, including 8mm, 12mm, 16mm, and 24mm tape widths.

3. How is the latch installed?

The latch mounts at the feeder’s front end and clips or snaps into the feeder mounting bracket. Installation typically requires no special tools.

4. What materials is the latch made from?

Manufactured from durable reinforced plastic or metal to withstand repeated use and mechanical stress.

5. What problems occur if the latch is missing or damaged?

Feeder may loosen or detach during operation.
Component pick-up accuracy may decrease due to feeder vibration.
Increased machine downtime from feeder misalignment errors.

6. Can the latch be replaced separately?

Yes, the front-end hook safety latch can usually be replaced independently without swapping the entire feeder assembly.

7. How often should the latch be inspected or replaced?

Regular visual inspection during routine maintenance is recommended. Replace if any cracks, deformation, or wear are detected.

8. Is special training required to operate or maintain the latch?

No special training is required. Operators should follow standard feeder mounting and safety procedures.

9. Are there accessories related to the latch?

Yes, related parts include mounting brackets, locking pins, spring clips, and release levers.

10. Where can I get replacement parts?

Replacement parts and accessories can be sourced from your SMT equipment supplier or authorized parts distributor.
