9090-41J062 10×5 Cylinder Straight Quick Coupler
9090-41J062 10×5 Cylinder Straight Quick Coupler
Specifications
Model Number :
KHY-9090-41J062
MOQ :
1 set of machine or mixed order is also acceptable Transport: By Bulk or Containers
Packaging Details :
Standard export boxes and sturdy hardwood packages are both options
Delivery Time :
1-2 Working days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,MoneyGram
Price :
Negotiable
Certification :
CE-9090-41J062
Place of Origin :
JAPAN
Brand Name :
YAMAHA
Description
9090-41J062 10×5 Cylinder Straight Quick Coupler
Model 9090-41J062 is a dedicated 10×5 straight quick pneumatic connector designed specifically for Yamaha chip mounters. This precision component features nickel plating for superior rust resistance and high-performance sealing rings that maintain excellent airtightness without pressure leakage.
9090-41J062 10×5 Cylinder Straight Quick Coupler
Manufactured to original dimensions for perfect fit, this quick coupler locks automatically for tool-free installation. Compatible with YS12 and YG12 models, it stabilizes pneumatic clamping, reduces air pressure malfunctions, and enables easy maintenance with extended service life.
Core Functions
  • Designed for Yamaha series mounter pneumatic circuits, this 10×5 cylindrical quick connector rapidly connects air cylinders and tubes to deliver compressed air for edge clamping, feeding, and other pneumatic mechanisms
  • Self-locking quick-plug design enables tool-free assembly and disassembly while built-in sealing structure prevents air leakage and stabilizes pressure output
  • Secures air circuit joints and cushions pressure fluctuations during pneumatic start/stop cycles, preventing loose clamping and equipment jams caused by unstable air pressure
Parameter Specifications
Part Number9090-41J062
Product NameCylinder Joint Connected to Fast Cylinder
BrandYAMAHA
Applicable ModelsYamaha YS12, YG12 SMT machine pneumatic clamp, Feida pneumatic components
SupplierFactory direct sales
ConditionBrand new original
Interface Specification10 × 5 cylinder joint connected to quick cylinder
Suitable Pipe Diameter5mm outer diameter trachea
Structural FormDirect insertion self-locking, tool free insertion and removal
Surface TreatmentRust resistant electroplating, resistant to corrosion in pneumatic environments
Sealing StructureBuilt in rubber sealing ring, high-pressure airtight and leak proof
Compatible EquipmentYamaha YS12, YG12 surface mount machine pneumatic clamp, Feida pneumatic components
Working MediumCompressed air, compatible with equipment standard working pressure
Product Promotion
CNSMT specializes in producing 9090-41J062 cylindrical quick-release cylinder connectors compatible with Yamaha YS12 and YG12 mounters. With precision sealing and nickel-plated anti-rust treatment, our brand-new original parts are well-stocked for global supply at cost-effective prices. We provide comprehensive after-sales warranty to stabilize pneumatic system operation and lower breakdown losses.
