HNP type nitrogen purification equipment operates continuously for 24 hours
HNP type nitrogen purification equipment operates continuously for 24 hours
Specifications
Brand Name :
CNSMT
Model Number :
HN-4060
Certification :
CE- hydrogen production
Place of Origin :
CHINA
MOQ :
1 set of machine or mixed order is also acceptable Transport: By Bulk or Containers
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,MoneyGram
Delivery Time :
1-2 Working days
Packaging Details :
Standard export boxes and sturdy hardwood packages are both options
Purity :
≥99.9995%
O,content :
n≤5ppm
Dew point :
≤-60°C
Control power supply :
0.2kw 220v 50Hz
Description
HNP Type Nitrogen Purification Equipment
Professional hydrogenation purification equipment operating continuously for 24 hours with excellent purification performance for SMT reflow soldering applications.
Key Features
  • Advanced hydrogenation purification process with palladium catalytic deoxygenation technology
  • Multi-stage deoxygenation, dehydrogenation, deep drying and precision filtration
  • Purifies ordinary nitrogen to 99.999% ultra-high purity
  • Intelligent PLC control system with fully automated operation
  • 24-hour uninterrupted continuous operation capability
  • Integrated cabinet modular structure with compact design
  • Complete safety protection with pressure monitoring and fault interlock systems
  • Cost-effective replacement for bottled high-purity nitrogen and liquid nitrogen
Working Principle
The HNP nitrogen purification equipment utilizes hydrogenation catalytic deoxygenation as its core process. Raw nitrogen and hydrogen are thoroughly mixed, with deoxygenation reactions completed under palladium catalyst action. Subsequent dehydrogenation, deep drying, and precision filtration processes remove moisture, impurities, and residual hydrogen to produce high-purity, low dew point clean nitrogen gas.
HNP type nitrogen purification equipment operates continuously for 24 hours
This specialized hydrogenation catalytic deoxygenation purification equipment is designed for precision electronic manufacturing, serving as the mainstream reflow soldering high-purity nitrogen solution in the SMT industry.
HNP type nitrogen purification equipment operates continuously for 24 hours
Technical Specifications
Model Output Nitrogen Purity Dimensions (L*W*H mm) Air Inlet Gas Outlet Weight (kg) Power Supply
HN4010 10Nm³/h ≥99.99% 1300*950*1850 G1/2" G1/2" 500 AC220V/0.2KW
HN4020 20Nm³/h ≥99.99% 1400*950*1850 G1" G1/2" 600 AC220V/0.2KW
HN4030 30Nm³/h ≥99.99% 1500*950*1850 G1" G1/2" 700 AC220V/0.2KW
HN4040 40Nm³/h ≥99.99% 1600*1000*2000 G1" G1/2" 800 AC220V/0.2KW
HN4050 50Nm³/h ≥99.99% 1600*1200*2200 G1" G1/4" 1000 AC220V/0.2KW
HN4060 60Nm³/h ≥99.99% 1600*1200*2200 G1" G1" 1200 AC220V/0.2KW
HN4080 80Nm³/h ≥99.99% 1800*1400*2500 G1" G1" 1600 AC220V/0.2KW
HN4100 100Nm³/h ≥99.99% 2000*1600*2600 DN32 G1" 1800 AC220V/0.2KW
HN4150 150Nm³/h ≥99.99% 2200*1600*2700 DN40 G1" 2400 AC220V/0.2KW
HN4200 200Nm³/h ≥99.99% 2300*1600*2700 DN50 DN40 3000 AC220V/0.2KW
HN4250 250Nm³/h ≥99.99% 2400*1600*2700 DN50 DN40 4000 AC220V/0.2KW
HN4300 300Nm³/h ≥99.99% 2500*1600*2760 DN65 DN40 5600 AC220V/0.2KW
HN4400 400Nm³/h ≥99.99% 2700*1800*2900 DN65 DN50 6500 AC220V/0.2KW
HN4500 500Nm³/h ≥99.99% 3200*2400*3900 DN80 DN65 7500 AC220V/0.2KW
HN4600 600Nm³/h ≥99.99% 3500*2500*4000 DN80 DN65 8500 AC220V/0.2KW
HN4700 700Nm³/h ≥99.99% 3500*2500*4500 DN100 DN80 9500 AC220V/0.2KW
HN4800 800Nm³/h ≥99.99% 3800*2600*4500 DN100 DN80 11000 AC220V/0.2KW
HN4900 900Nm³/h ≥99.99% 3800*2600*5200 DN100 DN80 12000 AC220V/0.2KW
HN41000 1000Nm³/h ≥99.99% 4000*2800*5500 DN100 DN80 15000 AC220V/0.2KW
Applications
SMT reflow soldering, precision electronics, semiconductor packaging, automotive electronics, industrial control product processing, and various high-end electronic manufacturing scenarios.
HNP type nitrogen purification equipment operates continuously for 24 hours
Service Support
Comprehensive pre-sales technical consultation, project solution design, equipment monitoring, training courseware, and personalized planning services. Global service network with distributed engineers equipped with specialized tools and spare parts for prompt on-site support.

Customer feedback and after-sales communication

HNP type nitrogen purification equipment operates continuously for 24 hours

Customers are satisfied with HNP nitrogen purifier for stable purity and low power consumption. Our after-sales team responds quickly to handle installation and technical issues. Superior products and thoughtful service gain favorable comments and repeat orders.

HNP type nitrogen purification equipment operates continuously for 24 hours
Certifications
HNP type nitrogen purification equipment operates continuously for 24 hours HNP type nitrogen purification equipment operates continuously for 24 hours

CNSMT manufactures HNP nitrogen purification equipment with high purification precision, energy-saving and stable performance for electronics and heat treatment industries. Our high-quality products sell globally at competitive prices to reduce clients’ gas cost. Complete after-sales including installation, commissioning and maintenance is available with fast response. We welcome your orders.
