LPT3535ER331LP Common Mode Choke Minimal EMI Radiation DC/DC Converter Applications
LPT3535ER331LP Common Mode Choke Minimal EMI Radiation DC/DC Converter Applications
Specifications
Brand Name :
Shareway
Model Number :
LPT3535ER331LP
Certification :
RoHS,ISO9001-2001
Place of Origin :
Guangdong,shenzhen
MOQ :
500/1000
Price :
Supportive
Payment Terms :
TT,Paypal,West Union
Supply Ability :
1kk-pcs/month
Delivery Time :
Stock Or 3 weeks
Packaging Details :
Reel/Tray
Product name :
LPT3535ER331LP Toroidal Choke for minimal EMI radiation in DC/DC converter applications
Feature :
Minimal EMI radiation
Application :
DC/DC converter applications
DCR :
0.004 To 1.463Ω
Inductance :
1.0 to 330uH
Material :
Powerered iron
Description

LPT3535ER331LP Toroidal Choke for minimal EMI radiation in DC/DC converter applications

Description:

  • Toroidal design for minimal EMI radiation in DC/DC
    converter applications
  • Designed to support the growing need for efficient
    DC/DC converters in battery operated equipment
  • Two separate windings provide versatility by ability to
    connect windings in series or parallel

STANDARD ELECTRICAL SPECIFICATIONS:

MODEL STD. IND.
(μH)		 IND. TOL. ACTUAL IND. (LOC)
(μH)		 DCR
(Ω)		 RATED IDC
(40 °C) (A)		 IND. AT IDC (LBIAS)
(30 %)
LPT3535ER1R0LP 1.0 ± 15 % 0.882 0.004 5.10 0.56 at 4.29
LPT3535ER1R5LP 1.5 ± 15 % 1.57 0.005 4.48 0.99 at 3.21
LPT3535ER2R5LP 2.5 ± 15 % 2.45 0.009 3.58 1.54 at 2.57
LPT3535ER3R3LP 3.3 ± 15 % 3.53 0.013 2.96 2.22 at 2.14
LPT3535ER5R0LP 5.0 ± 15 % 4.80 0.018 2.41 3.03 at 1.84
LPT3535ER100LP 10 ± 15 % 10.8 0.043 1.58 6.81 at 1.22
LPT3535ER150LP 15 ± 15 % 15.3 0.064 1.29 9.65 at 1.03
LPT3535ER250LP 25 ± 15 % 25.1 0.103 1.03 15.8 at 0.80
LPT3535ER330LP 33 ± 15 % 33.5 0.147 0.85 21.1 at 0.70
LPT3535ER500LP 50 ± 15 % 51.8 0.230 0.68 32.7 at 0.56
LPT3535ER101LP 100 ± 15 % 104 0.424 0.51 65.2 at 0.40
LPT3535ER151LP 150 ± 15 % 153 0.645 0.41 96.3 at 0.33
LPT3535ER251LP 250 ± 15 % 250 1.031 0.33 157.0 at 0.25
LPT3535ER331LP 330 ± 15 % 330 1.463 0.27 208.0 at 0.22

Dimensions:

LPT3535ER331LP Common Mode Choke Minimal EMI Radiation DC/DC Converter Applications
