Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Epistar 3V 5050 SMD LED Chip with Gold Wire Bond and 10000 Hours Lifespan for High Power LED Applications
Specifications
Brand Name :
Learnew
Place of Origin :
Guangdong, China
MOQ :
5000
Price :
$0.28-0.33
Chip Material :
Ingan
Color Temperature :
3000K-6000K
Input Voltage :
3.0-3.4V
Lifespan :
10000 Hours
Operating Temperature :
-20 - 80℃
Optical Attenuation :
0.3%
Power :
3W
Storage Temperature :
-40 - 110℃
Viewing Angle :
120°
Outline Dimension :
3.5*3.5MM;5.0*5.0MM
Substrate :
Ceramic
Power Dissipation :
5W;10W
Chips PKG Model :
Epiled & Flip CHIP
Color Rendering Index :
90
Working Time :
10000 Hours
Description

Better than 2835 5730 smd led

(We choose gold wire with high conductivity, good thermal conductivity, corrosion resistance, good toughness, good chemical stability, stable product performance and other advantages, high-end packaging technology selection. )

POWER DISSIPATION:

5W;10W

COB SIZE:

3.5*3.5MM;5.0*5.0MM

VIEW ANGLE:

120DEG
CHIPS PKG MODEL:

Epiled & Flip CHIP

SUBSTATE LOAD:

Ceramic

MANUFACTURER:

LEARNEW OPTO

Application of led chip high power

1.Roadway lighting: Street light, Garden light, Tunnel light
2.Indoor ligting: Spot light, Ceiling light bulb and so on.
Architectural lighting landscapes, lighting exterior illumination, etc.
Wall lamps, underwater lamps, decorative illumination, and more Underground lamps,reading lamps, emergency lights, and interior illumination Miner's lamps, flashlights, and car lamps.

Cautions 1w high power led chip, 3w high power led chip

1)Soldering Conditions

Number of reflow process shall be less than 2 times and cooling process to normal temperature is required between first and Second soldering process.

2)Static Electricity

It is recommended that a wrist band or an anti-electrostatic glove be used when handling the LEDs.All devices, equipment and machinery must be properly grounded.Damaged LEDs will show some unusual characteristics such as the forward voltage becomes lower, or the LEDs do not light at the low current. Criteria : (VF > 2.0V at IF=0.5mA)

3)Storage

Before opening the package ,The LEDs should be kept at 30°C or less and 70%RH or less. The LEDs should be used within a year.

4)Moisture Proof Package

Company Information

Packaging & Shipping

FAQ

Q1: Do you supply OEM,ODM service?

A1: YES,absolutely it can be realized.

Q2: All the pictures are real photo?

A2: Yes, the pictures of all products on this page are 100% real shoot by us.

Q3: How can I get a quotation from you?

A3: Please kindly leave us messages about your needs,including products and quantity,our professional team will reply you very soon (mostly within few hours).

Q4: Is there any discount for bulk order?

A4: Yes, if you need bulk order or you want customized products, we can provide wholesale price.

Q5: Do you support drop shipping and how much is the shippping cost?

A5: Yes, we support drop shipping. You should leave the receiver's information when you place the order, then we will send the goods according the address you have left. The shipping cost are based on your order's volume and weight, and it can be calculated.

Q6: How to place an order?

A6: If you want to place an order, Please feel free to send us an inquiry email or contact us by trademanager online, we will reply you within 24hours(working day).

Q7: What payment terms are available?

A7: T/T,PayPal, Western Union and Secure Payment.

Q8: What about the lead time?

A8: It depends on the order quantity. In general, lead time is about 3-75working days. For samples, the delivery could be as fast as same day.
