13.7A 4 Pin SOT-223 T/R Integrated Circuit Chips ACS108-8SN-TR TRIAC 800V 0.8A RMS
13.7A 4 Pin SOT-223 T/R Integrated Circuit Chips ACS108-8SN-TR TRIAC 800V 0.8A RMS
13.7A 4 Pin SOT-223 T/R Integrated Circuit Chips ACS108-8SN-TR TRIAC 800V 0.8A RMS
13.7A 4 Pin SOT-223 T/R Integrated Circuit Chips ACS108-8SN-TR TRIAC 800V 0.8A RMS
Specifications
Brand Name :
STMicroelectronics
Model Number :
ACS108-8SN-TR
Certification :
Original Part
Place of Origin :
Shenzhen, China
MOQ :
1PCS
Price :
to be Negotiated
Payment Terms :
T/T, Western Union, Paypal, Wechat Pay
Supply Ability :
1 Million pieces per Month
Delivery Time :
Immediate
Packaging Details :
SOT-223
Packaging :
SOT-223
Product Description :
TRIAC 800V 0.8A(RMS) 13.7A 4-Pin(3+Tab) SOT-223 T/R
Product Type :
Overvoltage protected AC switch (ACS™)
Package type :
Surface Mount
Condition :
Brand New and Original
Shipping by :
DHL\UPS\Fedex\EMS\HK Post
Description

ACS108-8SN-TR TRIAC 800V 0.8A(RMS) 13.7A 4-Pin(3+Tab) SOT-223 T/R


Applications :

  • Alternating current on/off static switching in appliances and industrial control systems
  • Driving low power high inductive or resistive loads like:

– relay, valve, solenoid, dispenser,

– pump, fan, low power motor, door lock,

– lamp.

Description :

The ACS108 belongs to the AC switch range (built with A. S. D.® technology). This high performance switch can control a load of up to 0.8 A. The ACS108 switch includes an overvoltage crowbar structure to absorb the inductive turn-off energy, and a gate level shifter driver to separate the digital controller from the main switch. It is triggered with a negative gate current flowing out of the gate pin.

Features :

  • Enables equipment to meet IEC 61000-4-5 surge with overvoltage crowbar technology.
  • High noise immunity against static dV/dt and IEC 61000-4-4 burst.
  • Needs no external protection snubber or varistor.
  • Reduces component count by up to 80% and Interfaces directly with the micro-controller.
  • Common package tab connection supports connection of several alternating current switches on the same cooling pad.
  • VCL gives headroom before clamping then crowbar action.

Basic Information :

Part No: ACS108-8SN-TR

Description: TRIAC 800V 0.8A(RMS) 13.7A 4-Pin(3+Tab) SOT-223 T/R

Package Length 6.5
Mounting Surface Mount
Package Width 3.5
Tab Tab
Lead Shape Gull-wing
PCB changed 3
Package Height 1.8(Max)
Maximum Rate of Rise of Off-State Voltage (V/us) 2000(Min)
Maximum Rate of Rise of On-State Current (A/us) 100
Maximum Gate Trigger Voltage (V) 1
Maximum Gate Trigger Current (mA) 10
Surge Current Rating (A) 13.7
Maximum Holding Current (mA) 10
Repetitive Peak Reverse Voltage (V) 800
Peak On-State Voltage (V) 1.3@1.1A
Repetitive Peak Forward Blocking Voltage (V) 800
RMS On-State Current (A) 0.8
Repetitive Peak Off-State Current (mA) 0.002
AC Switch Yes
Minimum Operating Temperature (°C) -30
Maximum Operating Temperature (°C) 125
Packaging Tape and Reel
Automotive No



for product datasheet, CONTACT US directly.
